Quick Details
-
Warranty:
-
1 year
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
Aibei
-
Model Number:
-
AB-DBH
-
Shank Type:
-
M14 or 5/8-11"
-
Material:
-
diamond powder and steel
-
Feature:
-
Good speed , dry wet
-
MOQ:
-
10 pcs per size
-
Application:
-
Granite , Marble , porcelain, tile, quartz
-
Diamond height:
-
50 mm
-
Total Height:
-
70 mm
-
Type of welding:
-
Vacuum brazed
-
Product name:
-
diamond finger drilling milling bit
-
Diameter:
-
10mm,15mm,20mm,25mm,30mm,35mm
Quick Details
-
Type:
-
Center Drill Bit, Core Drill Bit, Countersink Drill Bit, Spade Drill Bit
-
Use:
-
Masonry Drilling
-
Finish:
-
Other
-
Warranty:
-
1 year
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
Aibei
-
Model Number:
-
AB-DBH
-
Shank Type:
-
M14 or 5/8-11"
-
Material:
-
diamond powder and steel
-
Feature:
-
Good speed , dry wet
-
MOQ:
-
10 pcs per size
-
Application:
-
Granite , Marble , porcelain, tile, quartz
-
Diamond height:
-
50 mm
-
Total Height:
-
70 mm
-
Type of welding:
-
Vacuum brazed
-
Product name:
-
diamond finger drilling milling bit
-
Diameter:
-
10mm,15mm,20mm,25mm,30mm,35mm
Product Description
Main Feature:
Use: Dry and wet use
1.This kind diamond milling bit designed to enlarge, shape and/or round bevel existing holes in Porcelain, Hard Ceramic, Granite and Marble.
2.it is also suitable to easily create round side indentation necessary to suite pipes or electric wire lines.
3.This is a save money tool because with just one standard core bit + one diamond milling bit you are able to create many different hole sizes, without needing to buy several different core bits.
4.it is manufactured with top quality raw materials and high end production processes to granite outstanding performances.
5.It can be used with any standard grinder.No adaptors needed.
6.Recommended for Tile Setters, General Contractors, Plumbers and Electricians.
Attention! this kind of diamond milling bits isn’t designed to make holes. it is designed to shape and enlarge existing holes.
Specification
|
Article No.
|
Diameter(mm)
|
Length(mm)
|
Working length(mm)
|
Arbor
|
Grit
|
|
ABFB10
|
10
|
70
|
50
|
M14 or 5/8"-11
|
D427
|
|
ABFB15
|
15
|
70
|
50
|
M14 or 5/8"-11
|
D427
|
|
ABFB20
|
20
|
70
|
50
|
M14 or 5/8"-11
|
D427
|
|
ABFB25
|
25
|
70
|
50
|
M14 or 5/8"-11
|
D427
|
|
ABFB30
|
30
|
70
|
50
|
M14 or 5/8"-11
|
D427
|
|
ABFB35
|
35
|
70
|
50
|
M14 or 5/8"-11
|
D427
|
