Quick Details
-
Color:
-
Full color
-
Panel Size:
-
320mm*160mm
-
Place of Origin:
-
Shenzhen Guangdong ,China
-
Model Number:
-
P4
-
Brightness:
-
1000CD
-
pixel density:
-
80*40
-
Contrast Ratio:
-
4000:1
-
Color Depth:
-
3RGB in 1
-
Lifespan (hours):
-
100000
-
IP Rating:
-
65
-
HS Code:
-
8528591090
-
Resolution:
-
62500
-
View Angle（H/V）:
-
160°/140°
-
LED chip:
-
Epistar
-
LED type:
-
SMD1415
-
Cabinet Size:
-
960*960mm
-
Cabinet material:
-
Waterproof iron box
-
IP level:
-
IP65 or IP67
-
Warranty:
-
2 Years
-
Life span:
-
100000hours
-
Certificate:
-
FCC CE RoHS ISO IP65 SAA
Quick Details
-
Application:
-
Outdoor, Outdoor or Indoor,flexible stage
-
Type:
-
LED
-
Brand Name:
-
HXTody
-
Color:
-
Full color
-
Panel Size:
-
320mm*160mm
-
Place of Origin:
-
Shenzhen Guangdong ,China
-
Model Number:
-
P4
-
Brightness:
-
1000CD
-
pixel density:
-
80*40
-
Contrast Ratio:
-
4000:1
-
Color Depth:
-
3RGB in 1
-
Lifespan (hours):
-
100000
-
IP Rating:
-
65
-
HS Code:
-
8528591090
-
Resolution:
-
62500
-
View Angle（H/V）:
-
160°/140°
-
LED chip:
-
Epistar
-
LED type:
-
SMD1415
-
Cabinet Size:
-
960*960mm
-
Cabinet material:
-
Waterproof iron box
-
IP level:
-
IP65 or IP67
-
Warranty:
-
2 Years
-
Life span:
-
100000hours
-
Certificate:
-
FCC CE RoHS ISO IP65 SAA
Related Products
Product Description
Specifications
|
Item
|
Parameter
|
Parameter
|
Parameter
|
|
Pixel Pitch
|
3mm
|
4mm
|
4mm
|
|
LED Lamp
|
SMD1415
|
SMD1921
|
SMD1921
|
|
Density
|
111111dot/m2
|
62500dot/m2
|
62500dot/m2
|
|
Module Size
|
192*192mm
|
256*128mm
|
320*160mm
|
|
Module Pixels
|
64*64dot
|
64*32dot
|
80*40dot
|
|
Caninet Size
|
960mm*960mm
|
960mm*960mm
|
960mm*960mm
|
|
Cabinet Weight
|
40KG
|
40KG
|
40KG
|
|
Brightness/Adjustment
|
≥5200cd/m2
|
≥5800cd/m2
|
≥5800cd/m2
|
|
View Angle
|
≥160°/≥160°
|
≥160°/≥160°
|
≥160°/≥160°
|
|
Best View Distance
|
3m
|
4m
|
4m
|
|
Grey Scale
|
65536
|
65536
|
65536
|
|
Refresh Rate
|
≥1920Hz
|
≥1920Hz
|
≥1920Hz
|
|
Scan Mode
|
1/20 Scan
|
1/16 Scan
|
1/13 Scan
|
|
Life span
|
>100,000(Hrs)
|
>100,000(Hrs)
|
>100,000(Hrs)
|
|
MTBF
|
>5000(Hrs)
|
>5000(Hrs)
|
>5000(Hrs)
|
|
Out of control pixel rate
|
≥3/10,000(discrete distribution)
|
≥3/10,000(discrete distribution)
|
≥3/10,000(discrete distribution)
|
|
Operation Temperature
|
-10℃~+50℃
|
-10℃~+50℃
|
-10℃~+50℃
|
|
Working Humidity
|
10%~98%RH
|
10%~98%RH
|
10%~98%RH
|
|
Storage Temperature
|
-40℃~+85℃
|
-40℃~+85℃
|
-40℃~+85℃
|
|
Working Valtage
|
AC 110~240 V ±10%
|
AC 110~240 V ±10%
|
AC 110~240 V ±10%
|
|
IP Grade
|
IP67
|
IP67
|
IP67
|
Schematic of the control system
Packing and shipping
wooden box packaging
Delivery method
Application
P8 in Toronto
P6.67 in Toronto
P8 in Toronto
P5 in Japan
P10 in Xiamen
P10 in South Korea
Certifications
Our Factory
FAQ
