Quick Details
-
Weight (KG):
-
310
-
Voltage:
-
220V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Taichuan
-
Dimension(L*W*H):
-
L)1550X(W)820X(H)1450mm
-
Advantage:
-
Saving time and film
-
Control:
-
PLC or dual frequency control
-
Shape of sealed bag:
-
Back sealing
-
Film material:
-
Laminated film
-
Price terms:
-
FOB,EXW ,CIF
-
Certification:
-
CE Certification
Quick Details
-
Function:
-
FILLING, Wrapping, Labeling, Sealing
-
Packaging Type:
-
Bags, Film
-
Packaging Material:
-
Plastic, Paper
-
Weight (KG):
-
310
-
Voltage:
-
220V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Taichuan
-
Dimension(L*W*H):
-
L)1550X(W)820X(H)1450mm
-
Advantage:
-
Saving time and film
-
Control:
-
PLC or dual frequency control
-
Shape of sealed bag:
-
Back sealing
-
Film material:
-
Laminated film
-
Price terms:
-
FOB,EXW ,CIF
-
Certification:
-
CE Certification
A
uto packaging machinery
Simple operation
Easy maintenance
Durable
Efficient follow-up service
Packing simple
Main performance and structure features
1. Screw measuring, adjustment weight not need tools, with stable function, simple operation.
2. CPU single chip stop motor drawing film, screen adjustment parameters, easy operation.
3. Bag-making, filling, measuring, sealing, print date, product output in one poeration.
4. With powerful extended function, joint packing device, punching device, satisfide with difference product riquirement
Technical
| Model: | TCLB-160A | TCLB-160P/Y | TCLB-160F | TCLB-160B |
| Product | Grains | Liquid | Powder | |
| Measurment: | Volumetric cup | Pneumatic Pump | Auger feeding | Semi Automatic |
| Hopper capacity: | 40L | 40L | 15L | |
| Film width(Bag former): | Max.320mm (back seal 50-320mm , 3 side seal 50-300mm . 4 side seal 120-280mm) | |||
| Bag width | Max.150mm (back seal 20-150mm , 3 side seal 25-150mm . 4 side seal 60-140mm) | |||
| Bag length | 30-220mm ( If special order can do 250mm,280mm) | |||
| Measurement range | 20-250ml (if dosing cup max 120ml) | 1-20ml/20-50ml/50-125ml/125-250mm/250-500ml | 1-5ml/5-10ml/10-50ml/50-120ml/120-500ml | 20-250ml |
| Packing speed | 10-70bag/min | 10-70bag/min | 10-70bag/min | 10-70bag/min |
| Biggest film diameter | 300mm | 300mm | 300mm | 300mm |
| Film thickness | 0.04-0.08mm | 0.04-0.08mm | 0.04-0.08mm | 0.04-0.08mm |
| Packaging film materials | Laminate plastic film(OPP/CPP.OPP/CE.MST/PE) | |||
| Power | 220V,50/60HZ, Single Phase | |||
| Weight | 300KG | |||
| Machine size | L1100*W755*1730mm | |||
| Remark | Mechanical Type | |||
| Remark | Machine food touching part is stainless steel , body is carbon steel , if stainless steel covering add USD 200 , if 4 side seal add USD 100 ,EASY CUT FREE | |||
Taichuan BEST SERVICES:
A. The warranty would be one year. The damaged one(not include the part which is made damaged by man) can be changed by the supplier, but the demand-side needs to burden the transportation fee.
B.The above quotation is not include the maintenance fee which would happen at home or abroad. If the demand-side asks for maintenance door-to-door,then need to pay all the fees which will be charged.
INCLUDE SERVICE FEE USD 100/DAY,VISA FEE,ROUND-TRIP TICKET,ROOM AND BOARD ARE IN BUYER'S SIDE.
C. The supplier will provide the spare parts of the machine and support for technology for the good.
