Quick Details
-
Brand Name:
-
YaBo
-
Model Number:
-
LF4080
-
Battery Size:
-
32700
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
Approx. 5.5Kg
-
The charging ratio:
-
MAX. charge current 25A
-
The discharge rate:
-
MAX. Continuous discharge current 60A
-
Electric Energy:
-
640 Wh
-
Battery type:
-
12.8V 50Ah Lifepo4/Lithium Battery
-
Combination Method:
-
4S8P 32700 CELLS
-
Cycle Life:
-
4000 -6000Cycles
-
Max.Charging Voltage:
-
14.0~14.6V
-
Charging Current:
-
25A
-
Max.Charging Current:
-
50A
-
Max.Pulse Current:
-
100A(<3S)
-
Discharging Cut-off Voltage:
-
10.0
-
Size:
-
223*150*178*178mm
-
OEM/ODM:
-
Accepatable
Quick Details
-
Storage Type:
-
-10~45℃
-
Anode Material:
-
LFP
-
Application:
-
Power Tools, Home Appliances, Solar Energy Storage Systems, UPS,Solar,Wind Power System,Lighting,Communication Equipment
-
Brand Name:
-
YaBo
-
Model Number:
-
LF4080
-
Battery Size:
-
32700
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
Approx. 5.5Kg
-
The charging ratio:
-
MAX. charge current 25A
-
The discharge rate:
-
MAX. Continuous discharge current 60A
-
Electric Energy:
-
640 Wh
-
Battery type:
-
12.8V 50Ah Lifepo4/Lithium Battery
-
Combination Method:
-
4S8P 32700 CELLS
-
Cycle Life:
-
4000 -6000Cycles
-
Max.Charging Voltage:
-
14.0~14.6V
-
Charging Current:
-
25A
-
Max.Charging Current:
-
50A
-
Max.Pulse Current:
-
100A(<3S)
-
Discharging Cut-off Voltage:
-
10.0
-
Size:
-
223*150*178*178mm
-
OEM/ODM:
-
Accepatable
Product Description
|
Electrical
Characteristics |
Nominal Voltage
|
12.8V
|
|
|
Nominal Capacity
|
50Ah@0.2C
|
|
|
Energy
|
640Wh
|
|
|
Internal Resistance
|
≤50mΩ
|
|
|
Cycle Life
|
2000 Cycles @ 0.2C Charging/Discharging ,Until 70% Capacity
|
|
|
Self Discharge
|
≤3.5% per month at 25℃
|
|
Standard Charging
|
Max.Charging Voltage
|
14.0~14.6V
|
|
|
Charging Mode
|
At 0℃~45℃ temperature, charged to 14.6V at a constant current of 0.2C, and
then,changed continuously with constant voltage of 14.6V until the current was not more than 0.02C |
|
|
Charging Current
|
25A
|
|
|
Max.Charging Current
|
50A
|
|
Standard Discharging
|
Discharging Current
|
25A
|
|
|
Max. Continuous Current
|
50A
|
|
|
Max.Pulse Current
|
100A(<3S）
|
|
|
Discharging Cut-off Voltage
|
10.0
|
|
Operating Condition
|
Charge Temperature
|
0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
|
|
|
Discharge Temperature
|
-20℃ to 60℃(-4℉ to 140℉) @60±25% Relative Humidity
|
|
|
Storage Temperature
|
0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
|
|
|
Water Dust Resistance
|
IP55
|
|
Structure
|
Cell & Format
|
IFR32700 N60,4S8P
|
|
|
Casing
|
Plastic
|
|
|
Dimension(L*W*H*TH)
|
223*150*178*178
|
|
|
Weight
|
Approx. 5.5Kg
|
|
|
Terminal
|
M6
|
Details Images
Chart
Our Advantages
Features:
◆ Using the technology of lithium iron phosphate cell, superior safety,thousands of cycles, 100%DOD, under normal conditions.
◆ Built-in automatic protection for over-charge, over discharge, over current and over temperature.
◆ Free of maintenance .
◆ Internal cell balancing.
◆ Lighter weight: About 40% ~50% of the weight of a comparable lead acid battery.
◆ Can be charged using most standard lead-acid charges (set).
◆ Wider temperature range:-20℃~60℃.
◆ Support for Series application expansion (up to 51.2V) and two in parallels.
NOTES:
Do not use the 12V lithium battery pack in places with high humidity or where it may be exposed to wet.
Do not modify or disassemble the power bank.
Do not throw the 12V power bank into fire or water.
Do not reverse the polarity of the battery pack.
Do not modify or disassemble the power bank.
Do not throw the 12V power bank into fire or water.
Do not reverse the polarity of the battery pack.
Product Details
Application
* UPS
* Solar &Wind Power System
* Golf Cart
* Electric Vehicle , E-bike, E-rickshaw etc.
* Lighting
* Wheelchairs and scooters
* Solar &Wind Power System
* Golf Cart
* Electric Vehicle , E-bike, E-rickshaw etc.
* Lighting
* Wheelchairs and scooters
