Quick Details
-
Elongation (≥ %):
-
35
-
Place of Origin:
-
Jiangsu, China
-
Application:
-
Battery Connector, for18650 Li-ion Battery
-
Grade:
-
Fe ,Ni ,Co ,Al, Si ,Mn etc.
-
Ni (Min):
-
35%
-
Model Number:
-
Precision tube
-
Brand Name:
-
DZX
-
Product name:
-
Precision tube
-
Brand:
-
DZX
-
Material:
-
Invar 36
-
Shape:
-
wire
-
MOQ:
-
1kg
-
Series:
-
Precision alloy
-
Packing:
-
PVC+waterproof Paper+wooden Case
Quick Details
-
Resistance (μΩ.m):
-
stable, Low
-
Powder Or Not:
-
Not Powder
-
Ultimate Strength (≥ MPa):
-
690, Stable
-
Elongation (≥ %):
-
35
-
Place of Origin:
-
Jiangsu, China
-
Application:
-
Battery Connector, for18650 Li-ion Battery
-
Grade:
-
Fe ,Ni ,Co ,Al, Si ,Mn etc.
-
Ni (Min):
-
35%
-
Model Number:
-
Precision tube
-
Brand Name:
-
DZX
-
Product name:
-
Precision tube
-
Brand:
-
DZX
-
Material:
-
Invar 36
-
Shape:
-
wire
-
MOQ:
-
1kg
-
Series:
-
Precision alloy
-
Packing:
-
PVC+waterproof Paper+wooden Case
Product Description
4J29(Kovar),4J32,4J33,4J34,4J36(Invar),4J50 Round Tube
Grade: 4j29,4j36,4j42,4j43,4j44,4j47,4j50etc.
Sharp: wire, bar/rod, strip, sheet, tube
standard: GB/T15018,YB/T5231-2005,YB/T5241-2005,YB/T5235-2005etc.
Basic performance: It is divided into low-expansion alloy and fixed-expansion alloy, the latter is also known as sealing alloy.
Expansion alloy besides has the specific thermal expansion coefficient, according to the different USES also requires a good sealing property, weldability and corrosion resistance, machinability and cutting, and in the use of expansion characteristics caused by the temperature range there is no obvious change of phase transformation, its product is commonly bar, sheet, strip, wire and tube and so on.
Expansion alloy applications: It is widely used in glass, metal and ceramic sealing in avionics and instruments, electric vacuum industry and other electronic devices, electric light source and other fields.
Grade: 4j29,4j36,4j42,4j43,4j44,4j47,4j50etc.
Sharp: wire, bar/rod, strip, sheet, tube
standard: GB/T15018,YB/T5231-2005,YB/T5241-2005,YB/T5235-2005etc.
Basic performance: It is divided into low-expansion alloy and fixed-expansion alloy, the latter is also known as sealing alloy.
Expansion alloy besides has the specific thermal expansion coefficient, according to the different USES also requires a good sealing property, weldability and corrosion resistance, machinability and cutting, and in the use of expansion characteristics caused by the temperature range there is no obvious change of phase transformation, its product is commonly bar, sheet, strip, wire and tube and so on.
Expansion alloy applications: It is widely used in glass, metal and ceramic sealing in avionics and instruments, electric vacuum industry and other electronic devices, electric light source and other fields.
|
Chemical Composition
|
|
|
|
|
|
|
|
|
|
|||||||||
|
C
|
Mn
|
Si
|
P
|
S
|
Cu
|
Ni
|
Co
|
V
|
Fe
|
|||||||||
|
（≤）
|
|
|
|
|
|
|
|
|
|
|||||||||
|
0.04
|
0.3
|
0.3
|
0.02
|
0.02
|
0.2
|
0.5
|
49.0-51.0
|
0.80-1.80
|
Bal.
|
|||||||||
|
Alloy Type
|
Trade Name
|
UNS No.
|
Specifications
|
Forms Of Supply
|
|
|
|
|||
|
|
|
|
|
Rod
|
Strip
|
Wire
|
Sheet
|
|||
|
Ni29Co17
|
Kovar
|
K94610
|
ASTM F15
|
√
|
√
|
√
|
√
|
|||
|
FeNi36
|
Invar 36
|
K93603
|
ASTM 1684
|
√
|
√
|
|
√
|
|||
|
FeNi32Co5
|
Super Invar 32-5
|
KI93500
|
ASTMF1684
|
√
|
√
|
|
√
|
|||
|
FeNi27Co25
|
Ceramvar
|
F1466
|
ASTMF1466
|
√
|
√
|
√
|
√
|
|||
|
FeNi42
|
Alloy 42
|
K94100
|
ASTM F30
|
√
|
√
|
|
√
|
|||
|
FeNi46
|
Alloy 46
|
K94600
|
ASTM F30
|
√
|
√
|
|
√
|
|||
|
FeNi48
|
Alloy 48
|
K94800
|
ASTMF30
|
√
|
√
|
|
√
|
|||
|
FeNi50
|
Alloy 52
|
K95050
|
ASTM F30
|
√
|
√
|
|
√
|
|||
|
Shape
|
Size(mm)
|
|
Wire
|
0.5-7.5
|
|
Rod/Bar
|
8.0-200
|
|
Strip
|
(0.5-2.5)*(5-180)
|
|
Tube
|
custom made
|
|
Plate
|
custom made
|
For more details, pls directly contact us.
Application
Precision alloy tubes are widely used in various fields due to their unique physical and chemical properties, such as high precision, high strength, high temperature resistance, and excellent corrosion resistance. The application areas of precision alloy tubes include but are not limited to the following:
1. Electronic industry: Precision alloy tubes can be used in the production of electronic components such as thermocouples, temperature sensors, and resistance wires.
2. . Aerospace industry: Precision alloy tubes can be used in aerospace applications such as satellites, rockets, and aircraft due to their high strength and high temperature resistance.
3. Nuclear industry: Precision alloy tubes can be used in nuclear power plants for fuel cladding, control rods, and reactor pressure vessels.
4. Automotive industry: Precision alloy tubes can be used in automotive applications such as exhaust systems, fuel injection systems, and sensors due to their high precision and corrosion resistance.
5. Petrochemical industry: Precision alloy tubes can be used in petrochemical applications such as heat exchangers, condensers, and distillation columns due to their excellent corrosion resistance.
In summary, precision alloy tubes have a wide range of applications in various fields such as electronic, medical, aerospace, nuclear, automotive, and petrochemical industries due to their unique physical and chemical properties.
Production process
Customized service
OEM Services
We offer personalized customization services for both products and labels to meet the specific needs of our customers. We can provide products with different thicknesses and widths according to the customer's requirements. Whatever kind of customization service our customers need, we will do our best to meet their demands and ensure customer satisfaction.
Recommend Products
Why Choose Us
Jiangsu Dzx Technology Co., Ltd.
DLX Alloy is a company dedicated to the production and research and development of alloys. Founded in 2002, we initially focused on the production of resistance alloys. Over the past 20 years, we have continued to conduct research and development and now offer a range of alloy products, including Inconel, Monel, Hastelloy, high-temperature alloys, and other nickel-based alloys. Our commitment to meeting the needs of industries that require high strength, strong corrosion resistance, and high-temperature performance is reflected in our focus on developing these alloys.
Packing&shipping
Products packaging:
We can provide different packaging methods according to your requirements, such as wooden boxes, pallets, cardboard boxes, etc.,
to meet your specific requirements. Our packaging materials have been carefully selected to protect nickel based tubes from
moisture, pollution, and damage. Our packaging process strictly follows international standards to ensure that the nickel based tubes you receive are of high quality and non-destructive.
to meet your specific requirements. Our packaging materials have been carefully selected to protect nickel based tubes from
moisture, pollution, and damage. Our packaging process strictly follows international standards to ensure that the nickel based tubes you receive are of high quality and non-destructive.
FAQ
What is your working time and contacting information?
Monday-Saturday : 7:30AM-17:00PM (Beijing time, GMT+08.00) We have public holiday during May.1-3,
Oct.1-7 and Chinese New Year holiday . Pls email us during our holiday if u have any question.
Do you provide free samples?
Yes,we can provide a free sample for testing,buyer should bear all the shipping costs.
What is your payment terms?
T/T,L/C,D/A,D/P,Western Union,MoneyGram,Paypal
What is the lead time?
Usually sample lead time is 7 days after payment has been confirmed.
Oct.1-7 and Chinese New Year holiday . Pls email us during our holiday if u have any question.
Do you provide free samples?
Yes,we can provide a free sample for testing,buyer should bear all the shipping costs.
What is your payment terms?
T/T,L/C,D/A,D/P,Western Union,MoneyGram,Paypal
What is the lead time?
Usually sample lead time is 7 days after payment has been confirmed.
