Quick Details
-
Power:
-
50-1000KW
-
Dimension(L*W*H):
-
Customizable
-
Weight:
-
50000 kg
-
Product name:
-
Best Price Calculation Lime Rotary Kiln For Construction
-
Application:
-
Active Lime Plant
-
Capacity:
-
50-1000tpd
-
Spare Parts Supply:
-
Supply at lowest price
-
Installation and trial:
-
Send Engineer
-
Factory Visit:
-
Invitation Letter
-
Design drawings:
-
Provided
-
Quality:
-
International Standard
-
Calcination material:
-
Limestone, Cement clinker
-
After-sales Service Provided:
-
Online support
Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
UNISHINE
-
Voltage:
-
220-480V
-
Power:
-
50-1000KW
-
Dimension(L*W*H):
-
Customizable
-
Weight:
-
50000 kg
-
Product name:
-
Best Price Calculation Lime Rotary Kiln For Construction
-
Application:
-
Active Lime Plant
-
Capacity:
-
50-1000tpd
-
Spare Parts Supply:
-
Supply at lowest price
-
Installation and trial:
-
Send Engineer
-
Factory Visit:
-
Invitation Letter
-
Design drawings:
-
Provided
-
Quality:
-
International Standard
-
Calcination material:
-
Limestone, Cement clinker
-
After-sales Service Provided:
-
Online support
|
Model |
Diameter of cylinder (mm) |
Length of cylinder (mm) |
Inclination (%) |
Capacity (t/h) |
Rotation speed (rpm) |
Power (kw) |
Weight (t) |
|
YZ1225 |
1200 | 25000 | 4 | 3 |
0.53-5.25 |
22 | 34 |
|
YZ1632 |
1600 | 32000 | 4 | 3.5 |
0.53-5.25 |
15 | 46.82 |
|
YZ1828 |
1800 | 28000 | 4 | 4 |
0.28-2.84 |
30 | 59.39 |
|
YZ1845 |
1800 | 45000 | 4 | 4.5 |
0.28-2.84 |
30 | 80 |
|
YZ1636 |
1600 | 36000 | 4 | 1.2-1.9 |
0.26-2.61 |
22 | 51.023 |
|
YZ1939 |
1900 | 3900 | 4 | 1.6-3.4 |
0.31-2.82 |
37 | 70.704 |
|
YZ2044 |
2000 | 44000 | 3.5 | 2.4-4 |
0.22-2.26 |
37 | 97.135 |
|
YZ2245 |
2200 | 45000 | 3.5 | 3.2-5.3 |
0.23-2.25 |
45 | 125.462 |
|
YZ2550 |
2500 | 50000 | 3.5 | 6.2-7.4 |
0.68-1.45 |
55 | 179.606 |
|
YZ2555 |
2500 |
55000 |
3 | 7.3-9.8 | 0.79-2.38 | 55 | 191.203 |
|
YZ2820 |
2800 |
20000 |
4 |
15-18 |
0.8-1.45 |
75 | 186.373 |
| YZ3028 | 3000 |
28000 |
4 | 18-23 |
0.8-1.45 |
75 | 180.737 |
| YZ3060 | 3000 | 60000 | 3.5 |
16-20 |
0.49-2.41 | 90 | 272.510 |
| YZ3226 | 3200 | 26000 | 4 | 22-27 | 0.8-1.45 | 90 | 185.107 |
| YZ3255 | 3200 | 55000 | 3.5 |
17-23 |
0.1-1.52 |
75 | 271.673 |
| YZ3529 | 3500 | 29000 | 4 |
28-40 |
0.16-1.38 |
110 | 238.031 |
|
YZ3560 |
3500 | 60000 | 3.5 | 28-40 | 0.65-2.25 | 125 | 347.872 |
| YZ4030 | 4000 | 30000 | 4 | 52-70 | 0.38-3.52 | 160 | 415.103 |
|
YZ4060 |
4000 | 60000 | 3.5 | 55-78 | 0.38-3.52 | 315 | 514.223 |
|
YZ4262 |
4200 | 62000 | 3.5 | 80-105 |
0.38-3.52 |
315 | 541.615 |
| YZ4565 | 4500 | 65000 | 3.5 |
110-140 |
0.38-3.52 |
420 | 609.526 |
| YZ4772 | 4700 | 72000 | 3.5 |
150-190 |
0.38-3.52 |
550 | 795.325 |
| YB1626 | 1600/1400 | 26000 | 4 | 0.7-11 |
0.41-3.85 |
18.5 | 38.621 |
|
YB1939 |
1900/1600 | 39000 | 4 |
2.2-2.7 |
0.27-2.58 |
22 | 60.841 |
| YB2245 | 2200/2000 | 45000 | 3.5 |
2.5-3.5 |
0.25-2.28 | 30 | 88.632 |
| YB2545 |
2500/2200 |
45000 | 3.5 | 4.5-6.2 | 0.25-2.18 | 45 | 102.367 |
| YB2845 |
2800/2500 |
45000 | 3.5 |
7.5-10 |
0.68-1.45 |
55 | 192.622 |
| YB3560 |
3500/3000 |
60000 | 3.5 |
23-32 |
0.65-2.28 | 125 | 310.263 |
Aluminum Ash Rotary Kiln
Capacity: 50-500t/d
Applicable materials: Aluminum ash, calcium aluminate, clay, dolomite, refractory materials, coke, special materials, etc.
Application: Widely used in cement, building materials, metallurgy, chemical, mineral processing and other industries.
Brief Introduction: The use of rotary kiln to recover aluminum ash not only greatly improves the output and the purity of aluminum alloy, but also improves the environment.
Introduction
Electrolytic aluminum or cast aluminum will produce a large amount of scum during the production process. We call this scum as aluminum ash. Aluminum ash contains a relatively high content of metallic aluminum. Using rotary kiln to recover aluminum ash can not only greatly improve the output and purity of aluminum alloy, but also improve the environment.
Characteristics
1. The aluminum ash rotary kiln has the characteristics of simple structure, reliable operation and easy control of the production process.
2. The new technology aluminum ash rotary kiln overcomes the burning problem of high calorific value of coke oven gas and short flame, which can make full use of the remaining coke oven gas.
3. Aluminum ash rotary kiln is suitable for small and medium-sized iron and steel enterprises, coking enterprises, calcium carbide enterprises, and refractory materials industry, with very good energy-saving, environmental protection and efficiency-increasing effects.
