Quick Details
-
Model Number:
-
YB1208300-USB
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
722g
-
Product Name:
-
12.8v 8300mAh
-
Capacity:
-
8300(mA)
-
Dimension:
-
39*79*133 mm
-
Category:
-
Rechargeable Batteries
-
OEM/ODM:
-
Warmly Welcomed
-
Case:
-
Plastic
-
Certification:
-
CE/IEC/RoHS/UN38.3/MSDS/FCC
Quick Details
-
Anode Material:
-
NCM
-
Application:
-
LED Light Strip,CCTV CameraLaptop,martphone,Mobile Devices,GPSMergency Light,Backup Power Etc
-
Brand Name:
-
YABO/TalentCell
-
Model Number:
-
YB1208300-USB
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
722g
-
Product Name:
-
12.8v 8300mAh
-
Capacity:
-
8300(mA)
-
Dimension:
-
39*79*133 mm
-
Category:
-
Rechargeable Batteries
-
OEM/ODM:
-
Warmly Welcomed
-
Case:
-
Plastic
-
Certification:
-
CE/IEC/RoHS/UN38.3/MSDS/FCC
Product Description
|
Voltage(v)
|
12.8v
|
|
Capacity(mAh)
|
8300mAh
|
|
Max.charge/ discharge current(mA)
|
2500 mA
|
|
Case
|
Plastic
|
|
Led indicators
|
Green
|
|
|
|
|
Dimension(mm:T*W*L)
|
39*79*133 mm
|
|
Weight
|
500 g
|
|
Application
|
LED light bar products, CCTV camera, LED panel, video, speaker, car DVR, smart phoneLithium-ion battery pack can also operate
robot telescope |
|
|
|
|
|
|
|
|
12V / 6A (maximum) 8300mAh, 9V / 1A 11000mAh, 5V / 2A 20000mAh DC output lithium ion battery.
Compatible with any LED strip light products: CCTV camera, IP camera, essential oil diffuser, LED panel, amplifier, modem, Echo Show 8, car DVR, Spectra S2 breast pump. TalentCell lithium-ion battery pack also runs a robot telescope. Includes wall charger and DC 1 female to 2 male power splitter cable. ★ 【Be sure to turn on the battery switch (position "-") to charge. If not, it will not be charged. 】 |
|
|
|
Details Images
Product Advantage
5Safety Performance
|
Items
|
Test Method and Condition
|
Criteria
|
|
Thermal
exposure test |
Each fully charged cell,placed in a circulating air-convection oven. The oven temperature is raised at a rate of 5 °C/min ± 2 °C/min to a temperature of 130 °C ± 2 °C. The cell remains at this temperature for 30 min before the test is discontinued.
|
No explosion,No fire
|
|
Short test
|
The fully charged battery is to be short-circuited by connecting the
positive and negative terminals with resistance load not exceed 5mΩ.Tests are to be conducted at temperature 25±2℃ |
No explosion,No fire
The Temperature of the Battery surface not exceeded than 150℃ |
|
Over discharge
test |
After 1C charge，With 1C 90 minutes of constant current discharge and observed for 1 hour.
|
No explosion, No fire, No leakage
|
|
Over charge
test |
After 1C charge, continue to charge with a constant voltage 5.5V per a cell, holding 1h.
|
No explosion, No fire
|
|
Free fall test
|
After 1C charge, then drop the battery three times from a height of 1.5 m onto a concrete floor. The batteries are dropped so as to obtain impacts in random orientations and observe 1h.
|
No explosion, No fire，No leakage
|
|
Crush test
|
After 1C charge, Half a cylinder with a radius of 75 mm to (5 + 1mm)/s velocity perpendicular to the cell pressure, when the battery voltage reaches 0 v or deformation of 30% or stop pressing after extrusion of 200 kn.
|
No explosion,
No fire |
|
Seawater
immersion |
After 1C charge，All immersed in 3.5% brine concentration, to maintain a minimum of 2 hours or until thermal runaway when to stop，observe 1h.
|
No explosion, No fire
|
|
Temperature
cycle |
After 1C charge，Put the battery in 25 ℃ /-40 ℃, 25 ℃ / 85 ℃
condition transformation temperature,after repeat 5 times observe 1h |
No explosion, No fire
|
|
Low pressure
test |
After 1C charge，Into the low pressure experiment box, adjust air
pressure in the test chamber is 11.6 KP,Temperature to room temperature,take out after 6 h , observe 1h. |
No explosion, No fire, No leakage
|
