Quick Details
-
Weight:
-
2850 KG
-
Product name:
-
50 HP 4WD Small Farm Tractor With Front Loader Farming Equipment
-
Engine:
-
Diesel Engine
-
Color:
-
green/blue/yellow/red/black
-
Clutch:
-
Dual-stage
-
Horse power:
-
25hp-280hp
-
Implements:
-
Disc Plough Rotary Tiller Trailer
-
Drive:
-
4X4WD Wheel
-
Gear shift:
-
8f+2r/ 8f+8r
-
Model:
-
cabin/canopy/roll bar
-
attachment:
-
front loader/backhoe/blade
Quick Details
-
Brand Name:
-
TAVOL
-
Place of Origin:
-
China
-
Engine Brand:
-
YTO
-
Weight:
-
2850 KG
-
Product name:
-
50 HP 4WD Small Farm Tractor With Front Loader Farming Equipment
-
Engine:
-
Diesel Engine
-
Color:
-
green/blue/yellow/red/black
-
Clutch:
-
Dual-stage
-
Horse power:
-
25hp-280hp
-
Implements:
-
Disc Plough Rotary Tiller Trailer
-
Drive:
-
4X4WD Wheel
-
Gear shift:
-
8f+2r/ 8f+8r
-
Model:
-
cabin/canopy/roll bar
-
attachment:
-
front loader/backhoe/blade
price for sale high quality 50HP 4 wd agricultural garden tractor with front end loader attachments
|
Tavol 50hp Tactor Main Parameters
|
|
|
|
|||
|
Model
|
|
TL504
|
|
|||
|
Type
|
|
4x4
|
|
|||
|
Machine parameters
|
PTO power (KN)
|
31
|
|
|||
|
|
Rated Traction( KN)
|
10.5
|
|
|||
|
|
Dimensions(mm)
|
3315×1570×2350
|
|
|||
|
|
Wheelbase(mm)
|
1885
|
|
|||
|
|
Wheel base(mm)
|
Front wheel
|
1250
|
|||
|
|
|
Rear wheel
|
1000-1300
|
|||
|
|
Minimum ground clearance(mm)
|
|
295
|
|||
|
|
Turning circle radius
|
Unilateral braking
|
≤4.0
|
|||
|
|
|
Not unilateral braking
|
≤3.5
|
|||
|
|
Weight (KG)
|
|
1295
|
|||
|
Drive Train
|
Clutch
|
|
Single or dual stage clutch
|
|||
|
|
Gearbox
|
|
8+2 shift/8+8 shuttle shift
|
|||
|
Walking steering
|
Tire
|
Front wheel
|
6.00-16/6.5-16/7.5-16
|
|||
|
|
|
Rear wheel
|
9.5-24/11.2-24/12.4-24
|
|||
|
Working equipment
|
Maximum lifting force at 610mm(KN)
|
|
8.3
|
|||
|
|
Suspension mechanism
|
|
Three-point suspension type1
|
|||
|
|
Hydraulic output
|
|
Optional 1 or 2 groups
|
|||
|
PTO shaft
|
PTO speed r/min
|
|
540/760 or 540/1000
|
|||
|
Engine
|
Engine type
|
|
Diesel engine
|
|||
|
Start
|
Start method
|
|
Electric
|
|||
|
This parameter table is for reference only, everything is based on actual products
|
|
|
|
|||
Details Images
Assembly Process
Professional factory, advanced production equipment. The management system is perfect, the source process is firmly grasped, and the product quality is controlled.
Strict quality control process: laser blanking-stamping-processing-electrophoresis-coating-assembly
Strict quality control process: laser blanking-stamping-processing-electrophoresis-coating-assembly
Packing photo
Optional CKD&SKD Package/ Full & Farm containers
Main application
Whether it is paddy field or dry field, hilly or hillside, it can meet your different driving and working environment, help you to complete the farm work or traction work more quickly and efficiently.
Certifications
Tavol Group is a high-tech groups companies, which engage in high-end agricultural equipment manufacturing.Tavol Group is located at the foot of the world-famous Mountain Tai. Has Passed ISO9001, CE, SGS, BV, AAA, WIPO madrid international trademark, high-tech enterprise certification and special equipment manufacturing license etc.
Company information
Shandong Tavol Agricultural Machinery Co., Ltd
. are Focused on Development Of the Characteristic Agricultural Machinery, Like Paddy Fields, Mountains, Hills etc; High-end Intelligence, Like Unmanned Driving and Beidou Precision Agriculture; also Automation like CVT and Power Gear Shift etc. Products range: 25hp-280hp Farm Tractors and Other Farm Machines.
The Mission of Tavol Group is to Assemble the Best Tractors With the Best of Heart, and Strive for the Smiles of One billion Farmers; With the Values of Tolerance, Openness and Win-Win, Adopt Strict Production Technology and Inspection Standards, Select the Best Quality Brand Tractor Parts. To ensure a 100% Quality Standard, We will Independent Development and Production the Core Tractor Parts, Continue to Increase Investment in New Models and Technologies.
