Quick Details
-
Oiled or Non-oiled:
-
Slightly Oiled
-
Invoicing:
-
by actual weight
-
Place of Origin:
-
China
-
Outer Diameter:
-
73 - 630 mm
-
Thickness:
-
sch20 to schxxs up to 250mm
-
Grade:
-
x65
-
Delivery Time:
-
7days for stock
-
Type:
-
seamless/erw/lsaw/ssaw
-
quality guarantee:
-
nace/pmi/standard test
-
mtc:
-
en10204 3.1
-
Technology:
-
hot rolled/expanding
-
Surface:
-
3lpe coating/black oil painting
Quick Details
-
Section Shape:
-
Round
-
Surface Treatment:
-
black oil
-
Tolerance:
-
±10%
-
Oiled or Non-oiled:
-
Slightly Oiled
-
Invoicing:
-
by actual weight
-
Place of Origin:
-
China
-
Outer Diameter:
-
73 - 630 mm
-
Thickness:
-
sch20 to schxxs up to 250mm
-
Grade:
-
x65
-
Delivery Time:
-
7days for stock
-
Type:
-
seamless/erw/lsaw/ssaw
-
quality guarantee:
-
nace/pmi/standard test
-
mtc:
-
en10204 3.1
-
Technology:
-
hot rolled/expanding
-
Surface:
-
3lpe coating/black oil painting
API 5L Grade X42 / X46 / X52/ X56 /X60 / X65 / X70 / X80 PSL-1/PSL-2 ISO 3183 Carbon Steel Pipe
Grade X65 is a standard specified for gas, oil and water pipes by the American Petroleum Institute. API 5L X65 Pipe is high yield material meant for transportation of liquids over distance pipe lines. ISO 3183 L450 material have the minimum yield strength of 65000PSI and the minimum tensile strength of 77000PSI. API 5L X65 Seamless Pipe has two different product specifications. The PSL1 and PSL2 could be used interchangeably but the API 5L X65 PSL2 has some higher mechanical properties compared to PSL1. The API 5L X65 PSL1 is the most commonly used product specification level of API 5L Grade X65 ERW Pipe. The nominal bore size differs from 3/8 inches to 30 inches and the other dimensions vary according to the schedules. The API 5L X65 Grade B comes in beveled, coupling and in plain end forms.
|
Specifications |
|
|
Type |
Carbon Steel Line Pipe |
|
Standard |
API 5L / ISO 3183
|
|
Material |
PSL1/PSL2 Gr.A,Gr.B,X42,X46,X52,X56,X60,X65,X70
L210,L245,L290,L320,L360,L390,L415,L450,L485 |
|
Size Range |
3/8" NB To 30" NB
|
|
Technical |
Seamless: hot rolling, hot expanding
welding: ERW, SSAW, LSAW, HFW, JCOE |
|
Wall Thickness |
Schedule 20 To Schedule XXS Up to 250 mm Thickness |
|
Length |
LENGTH: 5.8/6/11.8/12m |
|
Surface |
Epoxy Coating / Colour Paint Coating / 3LPE Coating. |
|
Pipe Ends |
Plain Ends / Beveled Ends / Coupling |
|
Marking |
Logo, standard , material, size, heat no. |
|
Mechanical Test |
Flattening test, flaring test, hardness test, hydrostatic test, and tension test. |
|
Packing |
furnish bared, hex. bundles ,standard seaworthy. |
|
Mill's Test Certificate |
EN10204 3.1 |
|
Lead time |
7 days for stock, 30-35days for fresh production depend on quantity |
|
Payment term |
30% in advance, balance against packing list, commercial invoice, mill’s test certificate and pictures of product including dimension, visual and PMI test. |
|
After sales-service |
Change or compensation for any damages caused by manufacturing or transportation. |
