Quick Details
-
Type:
-
Air Source Heat Pump
-
Place of Origin:
-
Guangdong, China
-
Compressor:
-
DC Inverter Compressor
-
Power supply::
-
220V/1PH/50HZ
-
Max Hot Water Temperature:
-
75℃
-
Keyword:
-
Monoblock Heat Pump
-
Controller:
-
Wifi controller
Quick Details
-
Warranty:
-
3 years
-
Application:
-
Hotel, Commercial, Household
-
Power Source:
-
Electric
-
Type:
-
Air Source Heat Pump
-
Place of Origin:
-
Guangdong, China
-
Compressor:
-
DC Inverter Compressor
-
Power supply::
-
220V/1PH/50HZ
-
Max Hot Water Temperature:
-
75℃
-
Keyword:
-
Monoblock Heat Pump
-
Controller:
-
Wifi controller
Products Description
Features:
●
R290 refrigerant,low GWP(GWP=3)
●
Energy class: A+++
●
Heating+Cooling+DHW
●
Full DC inverter compressor and fan motor
●
-30℃ inverter
●
WIFI smart control
●
Outlet water temperature up to 75℃
Full DC Frequency Conversion Technology, with a Pleasant "0" Fluctuation
The heat pump adopts full DC frequency conversion technology to lock in a comfortable temperature range. It can adjust the operating temperature range in real time and adjust the operating power in real time. At the same time, it can achieve soft wind in summer and constant temperature and comfort in winter.
Stable operation of jet enthalpy enhancement technology at -35°C
Innovative use of the international leading level of jet enthalpy enhancement technology, the technology adopts the internationally renowned ultra-low temperature compressor, jet enthalpy enhancement technology, the use of a compressor, to achieve quasi-two-stage compression, -35 °C extremely cold weather can also operate normally.
The dual-rotor compressor operates steadily with 3D stereo noise reduction. It can run quietly like a library, allowing us to enjoy a quiet home environment.
Ten layers of security protection for peace of mind
From refrigerant, water flow to power supply, set up a ten-item all-round safety protection system, all-time and all-round escort, so that the equipment can operate more safely and stably.
Product Paramenters
|
Model
|
|
|
BLN-018TC3
|
|
|
Power supply
|
|
V/Ph/Hz
|
380~415/3/50
|
|
|
Nominal Heating (Max)
(A7/6℃,W30/35℃) |
Heating Capacity
|
kW
|
7.5~22.1
|
|
|
|
Power Input
|
kW
|
1.5~6.8
|
|
|
|
Current Input
|
W/W
|
2.7~12.3
|
|
|
Nominal Heating (Max)
(A7/6℃,W47/55℃) |
Heating Capacity
|
kW
|
7.0~18.9
|
|
|
|
Power Input
|
kW
|
2.15~7.35
|
|
|
|
Current Input
|
W/W
|
2.8~12.4
|
|
|
Nominal Cooling (Max)
(A35/24℃,W12/7℃) |
Cooling Capacity
|
kW
|
4.5~17.7
|
|
|
|
Power Input
|
kW
|
1.80~7.30
|
|
|
|
Current Input
|
W/W
|
3.3~12.9
|
|
|
ERP Level（Outlet water temp. at 35℃）
|
|
/
|
A+++
|
|
|
MAX. input power
|
|
kW
|
9.00
|
|
|
MAX. input current
|
|
A
|
16.00
|
|
|
Refrigerant
|
|
/
|
R290
|
|
|
Rated water flow
|
|
m³/h
|
3.00
|
|
|
Fan quantity
|
|
/
|
2
|
|
|
Fan motor type
|
|
/
|
DC inverter
|
|
|
Compressor
|
|
/
|
DC inverter
|
|
|
Circulating pump
|
|
/
|
Inverter type / Built-in
|
|
|
IP Class
|
|
/
|
IPX4
|
|
|
Sound pressure at 1m distance
|
|
dB(A)
|
48
|
|
|
Max outlet water temperature
|
|
°C
|
75
|
|
|
Water piping connections
|
|
/
|
DN 32 (1-1/4")
|
|
|
Water Pressure drop(max)
|
|
kPa
|
60
|
|
|
Operating temperature range (Heating mode)
|
|
°C
|
-30~45
|
|
|
Operating temperature range (Cooing mode)
|
|
°C
|
16~45
|
|
|
Unpacked Dimensions ( L×D×H )
|
|
mm
|
1285×455×1350
|
|
|
Packed Dimensions ( L×D×H )
|
|
mm
|
1450×530×1450
|
|
|
UnPacked Weight
|
|
kg
|
145
|
|
|
Packed Weight
|
|
kg
|
160
|
|
