Quick Details
-
Warranty:
-
10 years/ 25 years
-
Brand Name:
-
Oushang solar
-
Model Number:
-
OS-P36-165
-
Place of Origin:
-
Hebei, China
-
Panel Dimensions:
-
1480*670*35mm
-
Product name:
-
Monocrystalline Silicon Solar Panel
-
Cell Grade:
-
Grade A
-
Frame Material:
-
Anodized Aluminium Alloy
-
Front Glass:
-
Tempered Glass
-
Back Cover:
-
TPT(Composite film)
-
Cell Encapsulant:
-
EVA
-
Junction box:
-
IP67
-
Max wind load:
-
2400Pa
-
Max snow load:
-
5400Pa
-
Certificate:
-
ISO/TUV/INMETRO
Quick Details
-
Cell size:
-
1480*670*35
-
Type:
-
PERC
-
Panel Efficiency:
-
18%
-
Warranty:
-
10 years/ 25 years
-
Brand Name:
-
Oushang solar
-
Model Number:
-
OS-P36-165
-
Place of Origin:
-
Hebei, China
-
Panel Dimensions:
-
1480*670*35mm
-
Product name:
-
Monocrystalline Silicon Solar Panel
-
Cell Grade:
-
Grade A
-
Frame Material:
-
Anodized Aluminium Alloy
-
Front Glass:
-
Tempered Glass
-
Back Cover:
-
TPT(Composite film)
-
Cell Encapsulant:
-
EVA
-
Junction box:
-
IP67
-
Max wind load:
-
2400Pa
-
Max snow load:
-
5400Pa
-
Certificate:
-
ISO/TUV/INMETRO
|
Module Type
|
OS-P36-150
|
OS-P36-165
|
OS-P36-175
|
||
|
Maximum Power(Pmax)
|
150W
|
165W
|
175W
|
||
|
Maximum Power Voltage(Vmp)
|
18.0V
|
18.4V
|
18.9V
|
||
|
Maximum Power Current(lmp)
|
8.33A
|
8.98A
|
9.26A
|
||
|
Open Circuit Voltage(Voc)
|
21.4V
|
21.66V
|
22.49V
|
||
|
Short Circuit Current(lsc)
|
8.83A
|
9.14A
|
9.81A
|
||
|
Number of Cells
|
36(4*9)
|
36(4*9)
|
36(4*9)
|
||
|
Size of Cells(mm)
|
156*156
|
156*156
|
156*156
|
||
|
Dimensions(mm)
|
1480*670*35
|
1480*670*35
|
1480*670*35
|
||
|
Power Tolerance
|
±3%
|
|
|
||
|
Maximum System Voltage
|
1000VDC
|
|
|
||
Strict quality control
Mirror Observation
100% EL test before and after lamination
Visual inspection
IV test
1. Is your company a factory or trading company?
We design and produce solar panels of all sizes, customized solar panels, and we manufacture standard solar panel in our own factory. Not only do we have manufacturlng capability, but we are also TUV certified party for 3rd-party production supervision.
2. Can you do OEM and 0DM?
Yes. We provide a wide range of options for common panels and non-standard ones.
3. Can you do according to custom's request on panels?
We stick to provldling the professlonal sills and products on the basis of all our customers' dfferent requlrements.
4. What is your delivery time?
Common panels can be delvered between 2~3 weeks.
5. Can you provide sample?
Samples available for all sizes.for more details you can contact our sales representative.
6. Why order from Oushang Solar?
. Quality with excellent design;
. Meets major international standards;
. 24-hour response to any post sales service;
