Features:
* Object self induction
* Build in RS232 and USB interface
* Omni Directional Reading for all 1D/2D Barcodes.
* Can Read Paper&Barcode on Screen Even Without Backlight from Cellphone.
* Multiple Language Barcode Message Transfer.
- Product Details
- {{item.text}}
Quick Details
-
Optical Resolution:
-
640 pixels(H)*480 pixels(V)
-
Scan Speed:
-
1/200 sec
-
Brand Name:
-
MASUNG
-
Place of Origin:
-
Guangdong, China
-
Image Sensor:
-
Ratio (5: 4)
-
System Supported:
-
Linux, Android, Windows XP. 7, 8. 10,MAC
-
Reading ability:
-
Standdard 1D/2D Code
-
Scan Angle:
-
rotation angle = 360 ° elevation angle =60 °,deflection angle = 70 °.
-
Scan Mode:
-
Auto Sense Mode
-
Scan type:
-
1D/2D QR
-
Interface:
-
RS232/USB
-
Light Source:
-
llumination:6500K LED
-
Field of View:
-
72° (H) X 64°(V)
-
Motion Tolerances:
-
>2m/s
Quick Details
-
Type:
-
Barcode Scanner
-
Scan Element Type:
-
CMOS
-
Max Paper Size:
-
A4
-
Optical Resolution:
-
640 pixels(H)*480 pixels(V)
-
Scan Speed:
-
1/200 sec
-
Brand Name:
-
MASUNG
-
Place of Origin:
-
Guangdong, China
-
Image Sensor:
-
Ratio (5: 4)
-
System Supported:
-
Linux, Android, Windows XP. 7, 8. 10,MAC
-
Reading ability:
-
Standdard 1D/2D Code
-
Scan Angle:
-
rotation angle = 360 ° elevation angle =60 °,deflection angle = 70 °.
-
Scan Mode:
-
Auto Sense Mode
-
Scan type:
-
1D/2D QR
-
Interface:
-
RS232/USB
-
Light Source:
-
llumination:6500K LED
-
Field of View:
-
72° (H) X 64°(V)
-
Motion Tolerances:
-
>2m/s
Product Description
|
Product Features
|
|
|
|
Dimension:
|
77.5mm x 66mm x 45mm
|
|
|
Weight:
|
75g
|
|
|
Voltage:
|
3.3-5 VDC
|
|
|
Current:
|
200mA
|
|
|
Image (Pixels):
|
640 pixels (H)x 480 pixels(V)
|
|
|
Light Source:
|
Illumination:6500K LED
|
|
|
Field of View:
|
72° (H) x 64° (V)
|
|
|
Roll / Pitch / Yaw:
|
360°, ±65°, ±60°
|
|
|
Printing Contrast:
|
20% minimum reflective difference
|
|
|
Motion Tolerances
|
>2m/s
|
|
|
Interface:
|
USB, RS232
|
|
|
1-D:
|
UPC, EAN, Code 128, Code 39, Code 93, Code 11, Matrix 2 of 5, Codabar Interleaved 2
|
|
|
|
of 5, Mis Plessey, GSI DataBar, China Postal,
|
|
|
|
Korean Postal , etc
|
|
|
2-D:
|
PDF417, MicroPDF417, Data Matrix,Maxicode, QR Code, MicroQR, Aztec, Hanxin, etc.
|
|
|
Minimum Resolution:
|
≥3.9 mil
|
|
|
Operating Temperature:
|
-40°C to 70°C
|
|
|
Storage Temperature:
|
-50°C to 85°C
|
|
|
Humidity:
|
0% to 95% relative humidity,non condensing
|
|
|
Anti-Shock Specification
|
Designed to withstand 1.5m(5’) drops
|
|
|
Ambient Light Immunity:
|
0-100,000 Lux.
|
|
