Quick Details
-
Bending Precision (Deg):
-
90
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
TLP
-
Year:
-
1997
-
Power (kW):
-
1.5
-
Weight (KG):
-
260
-
Motor:
-
110/220/380v, 50 or 60 Hz
-
wall thickness of pipe:
-
0.5-2mm
-
round dies::
-
16, 19, 22&63, 25&51, 32&38, 76,mm
-
square dies:
-
30&50, 16&25&40, 19&22&38mm
-
Certificate:
-
CE and ISO9001
-
After-sales Service Provided:
-
Free spare parts;Online support;Video technical support
-
After Warranty Service:
-
Video technical support;Online support;Spare parts;
-
Application:
-
Round Pipe Bending
-
Certification:
-
ISO9001 CE
Quick Details
-
Machine Type:
-
BENDING MACHINE, Pipe and Tube Bending Machine
-
Bending Radius (mm):
-
8 - 38
-
Max. Bending Angle (Deg):
-
90
-
Bending Precision (Deg):
-
90
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
TLP
-
Year:
-
1997
-
Power (kW):
-
1.5
-
Weight (KG):
-
260
-
Motor:
-
110/220/380v, 50 or 60 Hz
-
wall thickness of pipe:
-
0.5-2mm
-
round dies::
-
16, 19, 22&63, 25&51, 32&38, 76,mm
-
square dies:
-
30&50, 16&25&40, 19&22&38mm
-
Certificate:
-
CE and ISO9001
-
After-sales Service Provided:
-
Free spare parts;Online support;Video technical support
-
After Warranty Service:
-
Video technical support;Online support;Spare parts;
-
Application:
-
Round Pipe Bending
-
Certification:
-
ISO9001 CE
|
|
Featrues
1. For making quick work of large radius bends and doing complete circles.
2. Especially applicable to the production of steel greenhouse frame.
3. Capable of rolling bending thin-walled mild steel, stainless steel round & square tubes.
4. Manual adjustment of top roll.
5. Two driving rollers and one driven roller.
6. Foot pedal with emergency stop available on request. This specially designed section and tube rolling machine can be used on either side front or rear of machine, the front is designed to handle the larger tube as the rear
7. is capable of rolling smaller tubes.
8. Toolings made of grey cast iron allows long service life.
|
Model |
Round formers (mm) |
Square formers (mm) |
Motor (mm) |
Woltage (volt) |
G.W. (Kg) |
Volume (mm) |
HHW-76B |
16,19,22,25,32,38,51,63,76 |
16,19,22,25,30,38,40,50 |
0.5-2 |
110V/220/380 |
260 |
730×630×1030 |
HHW-G76 |
16,19,22,25,32,38,51,63,76 |
16,19,22,25,30,38,40,50 |
0.5-2 |
110V/220/380 |
250 |
730×630×1030 |
We pack up the goods by carton case and deliver the goods within 20 days.
We take "Quality first, Customer utmost" as our principle and strive for customer satisfaction with our fine work in details. Our goal is to develop long-term business relationship with every customer we ever cooperate, by providing quality products and services, and continuous improvements.
