Quick Details
-
Brand Name:
-
TDER
-
Fork Length:
-
920mm
-
Fork Width:
-
120mm
-
Overall Dimensions:
-
2100*1100*2010mm
-
Weight (KG):
-
3420 kg
-
Unique selling points:
-
High quality
-
Motor:
-
Chinese famous brand ZIBO
-
Color:
-
Customized
-
Loading Capacity:
-
2000kg/3000kg
-
Tire:
-
Pneumatic Tire/Solid tires(optional)
-
Service:
-
Free spare parts
-
Wheelbase:
-
1460mm
-
Fork Size:
-
920*120*35
Quick Details
-
Min. Lifting Height:
-
3000mm
-
Warranty:
-
1 Year
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
TDER
-
Fork Length:
-
920mm
-
Fork Width:
-
120mm
-
Overall Dimensions:
-
2100*1100*2010mm
-
Weight (KG):
-
3420 kg
-
Unique selling points:
-
High quality
-
Motor:
-
Chinese famous brand ZIBO
-
Color:
-
Customized
-
Loading Capacity:
-
2000kg/3000kg
-
Tire:
-
Pneumatic Tire/Solid tires(optional)
-
Service:
-
Free spare parts
-
Wheelbase:
-
1460mm
-
Fork Size:
-
920*120*35
TDER Electric Forklifts
Products Description
2. EPS swerve can reduce 20% of the energy consumption. It is precise, flexible, and convenient to operate. At the same time, it can reduce driver fatigue, boost productivity.
3. Vertical AC drive, no carbon brush, free maintenance, highly efficient motor, accuracy control, powerfully output.
4. Small volume, low weight, small turn radius, easily enter into the elevator, suitable for working in floor or within the carriage, improved the pass-ability and space utilization.
5. The front wheel of the solid rubber tyres, strong grip, and stable operation.
6.The design of portal-frame has a buffer system, leaning back function.
7.Forklift temporary parking ramp adopt both electronically controlled and the foot brake to get a double insurance.
Product Paramenters
|
Model
|
|
FB10
|
FB15
|
FB18
|
FB20
|
FB25
|
|
Load capacity
|
kg
|
1000
|
1500
|
1800
|
2000
|
2500
|
|
Load center
|
mm
|
500
|
500
|
500
|
500
|
500
|
|
Mast height
|
mm
|
1995
|
1995
|
1995
|
1995
|
1995
|
|
Lifting height
|
mm
|
4025
|
4025
|
4025
|
4045
|
4045
|
|
Free lift height
|
mm
|
140
|
140
|
140
|
150
|
150
|
|
Standard mast height
|
mm
|
3000
|
3000
|
3000
|
3000
|
3000
|
|
Overhead guard height
|
mm
|
2100
|
2100
|
2100
|
2098
|
2098
|
|
Overall length
|
mm
|
2035
|
2035
|
2035
|
2353
|
2353
|
|
Fork overhang
|
mm
|
400
|
400
|
400
|
468.5
|
468.5
|
|
Wheelbase
|
mm
|
1360
|
1360
|
1360
|
1500
|
1500
|
|
Min. ground distance
|
mm
|
110
|
110
|
110
|
110
|
110
|
|
Fork size
|
mm
|
1070X122X45
|
1070X122X45
|
1070X122X45
|
1070X125X45
|
1070X125X45
|
|
Turning radius
|
mm
|
1997
|
1997
|
1997
|
2172
|
2172
|
|
Total weight
|
kg
|
2960
|
3120
|
3200
|
4214
|
4270
|
|
Model
|
|
FB30
|
FB35
|
FB50
|
FB55
|
FB60
|
|
Load capacity
|
kg
|
3000
|
3500
|
5000
|
5500
|
6000
|
|
Load center
|
mm
|
500
|
500
|
500
|
500
|
500
|
|
Mast height
|
mm
|
2025
|
2025
|
3000
|
3000
|
3000
|
|
Lifting height
|
mm
|
4160
|
4160
|
4280
|
4280
|
4280
|
|
Free lift height
|
mm
|
150
|
150
|
150
|
150
|
150
|
|
Standard mast height
|
mm
|
3000
|
3000
|
3000
|
3000
|
3000
|
|
Overhead guard height
|
mm
|
2092
|
2092
|
2255
|
2255
|
2255
|
|
Overall length
|
mm
|
2507
|
2507
|
3185
|
3185
|
3185
|
|
Fork overhang
|
mm
|
475
|
475
|
565
|
565
|
565
|
|
Wheelbase
|
mm
|
1600
|
1600
|
2100
|
2100
|
2100
|
|
Min. ground distance
|
mm
|
110
|
110
|
110
|
110
|
110
|
|
Fork size
|
mm
|
1070X125X45
|
1070X125X45
|
1070×150×50
|
1070×150×50
|
1220×150×60
|
|
Turning radius
|
mm
|
2360
|
2360
|
2930
|
2930
|
2930
|
|
Total weight
|
kg
|
4950
|
5010
|
7300/6720
|
8050/6185
|
8274/6184
|
