Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
GEC
-
Use:
-
Decoating,descalling,cleaning
-
Material:
-
Steel Container
-
Dimension(L*W*H):
-
4000*2000*1800mm
-
Marketing Type:
-
Hot Product 2023
-
Weight (KG):
-
4100 kg
-
High-Pressure Unit In Container:
-
G25024A2-3G-DW182C
-
High-Pressure Pump:
-
250GD3G
-
Flow rate:
-
60 L/min
-
Operating pressure:
-
1300 bar
-
Plunger Diameter:
-
24mm
-
Diesel engine:
-
WEICHAI
-
Speed:
-
1750r/min
-
L x W x H:
-
4000 x 2000 x 1800 mm
-
Weight:
-
4100kg
Quick Details
-
Cleaning Process:
-
Cold Water Cleaning
-
Power:
-
182KW, 182 KW
-
Max. Pressure:
-
160Mpa
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
GEC
-
Use:
-
Decoating,descalling,cleaning
-
Material:
-
Steel Container
-
Dimension(L*W*H):
-
4000*2000*1800mm
-
Marketing Type:
-
Hot Product 2023
-
Weight (KG):
-
4100 kg
-
High-Pressure Unit In Container:
-
G25024A2-3G-DW182C
-
High-Pressure Pump:
-
250GD3G
-
Flow rate:
-
60 L/min
-
Operating pressure:
-
1300 bar
-
Plunger Diameter:
-
24mm
-
Diesel engine:
-
WEICHAI
-
Speed:
-
1750r/min
-
L x W x H:
-
4000 x 2000 x 1800 mm
-
Weight:
-
4100kg
Product Application
|
Cleaning
|
Hull cleaning, aluminum formwork cleaning, pipe cleaning, condenser, heat exchanger, evaporation tank, boiler and other tank cleaning, aviation products, marine underwater cleaning
|
|
|
|
|||
|
Removal
|
Ship paint removal, landmark line removal, steel plant phosphorus removal, asbestos removal, chloride removal in concrete, pile corrosion removal, scale removal, deburring, etc
|
|
|
|
|||
|
Pretreatment
|
Marine surface treatment, highway overlay treatment, concrete surface treatment, other surface treatment
|
|
|
|
|||
|
Others
|
High-pressure water jet cutting, sewer dredging, high-pressure water roughening, cement demolition projects, spunlace non-woven fabrics, mechanical processing and manufacturing, water atomization pulverization, cylinder fatigue testing machine
|
|
|
|
|||
Products Description
The high-pressure plunger pump adopts the advanced technology of the United States, and has the characteristics of compact structure, small size, light weight and high efficiency.
The stuffing box and inner cavity parts can be replaced without disassembling the pump head, and various actuators can be connected. Long service life of components, low working temperature, stable operation of equipment, and various types of plunger diameters, which can meet different operating pressures on site.
Product Features
1.Stainless steel pump head adapted to alternating stress;
2.The middle rod seal is used in combination with two different types of seals;
3.Specially developed plunger seal;
4.Plunger made of hard alloy;
5.The crankshaft is designed according to the finite element method to ensure the reliability during operation;
6.The internal design of the herringbone gear is used to offset the axial force;
7.The external multi-point forced lubrication system ensures that each contact surface is fully lubricated;
8.The lubrication system is equipped with an overflow valve, which can ensure the oil pressure at 5bar at different input speeds; .
9.Active plunger connection effectively reduces the risk of eccentric wear.
Product Parameters
|
Flow rate
|
60 L/min
|
Diesel engine
|
WEICHAI
|
|
Operating pressure
|
1300 bar
|
Power
|
182 KW
|
|
Plunger Diameter
|
24mm
|
Speed
|
1750r/min
|
|
L x W x H
|
4000 x 2000 x 1800mm
|
Weight
|
4100kg
|
Product Show
Accessories
We have a variety of nozzle types to choose from, and different opening patterns can be selected according to your application, pressure and flow. The nozzle is made of steel, precision machining, no rust, strong wear resistance. It is suitable for all kinds of complex and different diameter pipelines, and completes all-round pipeline cleaning operations.
Haiba Bottom Nozzle
The nozzle for the bottom of the pipe, square ditch and other large pipe network of garbage, dirt, gravel, clay cleaning effect is super significant, is the traditional cleaning nozzle cleaning effect is incomparable. Different pressure flow of water energy consumption equipped with interchangeable nozzles, the effect can be more than 85%, basically no loss in the role of cleaning work.
Mitsubishi drill type nozzle
The nozzle has a strong ability to clear clogged pipes, silt, and gravel. With a high-strength drill tip and a three diamond shape design, it can be drilled into the blockage, and with a powerful water jet, it can instantly break through the blockage and then wash it away. Especially for the pipeline with a lot of oil, grease and dirt.
Mushroom head nozzle
The nozzle for unblocking small and medium-sized pipe diameter of a wide range of applications, during the operation will not jam the pipe, jamming, for different working conditions can be flexibly replaced by four kinds of nozzles used alternately, will be faster, more economical, and better to complete the unblocking and cleaning operations.
