Quick Details
-
Voltage:
-
380V
-
Power:
-
18kw
-
Dimension(L*W*H):
-
depends
-
Weight:
-
1000
-
Application fields:
-
candy factory
-
Machinery Capacity:
-
120-480kg/h
-
Machinery Function:
-
Automatic
-
Raw material:
-
sugar
-
Material:
-
Stainless Steel
-
Capacity:
-
120-480kg/h
-
Energy:
-
Electricity
-
Feature:
-
Economical
-
Suitable for:
-
lollipop candy making
Quick Details
-
Model Number:
-
KH150/300/450/600
-
Brand Name:
-
KH
-
Place of Origin:
-
Shanghai, China
-
Voltage:
-
380V
-
Power:
-
18kw
-
Dimension(L*W*H):
-
depends
-
Weight:
-
1000
-
Application fields:
-
candy factory
-
Machinery Capacity:
-
120-480kg/h
-
Machinery Function:
-
Automatic
-
Raw material:
-
sugar
-
Material:
-
Stainless Steel
-
Capacity:
-
120-480kg/h
-
Energy:
-
Electricity
-
Feature:
-
Economical
-
Suitable for:
-
lollipop candy making
PRODUCTS DESCRIPTION
KH150/300/450/600 AUTOMATIC PLC CONTROLLED BALL/ FLAT LOLLIPOP DEPOSITING PRODUCTION LINE
The production line is composed of sugar dissolving cooker,storage tank,candy vacuum micro-film cooker,depositing machine,molds and cooling tunnel.The production line can produce double color striped,double-color double-layer,single-color and central filled lollipops.Various kinds of depositing hard candies can be produced after the mold is replaced by customers. The production line adopts PLC to control candy vacuum cooking,conveying and depositing procedures.Rationed filling of essence, pigment and acid solution can be completed on the line.The machine is equipped with the automatic stick placing device with goods stability and reliability.The whole production line adopts sanitary design with compact structure and reliable performance.
THE DETAILS
THE MOLDS
THE SAMPLE
PRODUCTS PARAMETERS
|
Items
|
Model
|
KH-150
|
KH-300
|
KH-450
|
KH-600
|
|
|
production capacity
|
|
120kg/h
|
250kg/h
|
350kg/h
|
480kg/h
|
|
|
Weight of each candy
|
|
Max.16g
|
Max.16g
|
Max.16g
|
Max.16g
|
|
|
Depositing times
|
|
25n/min
|
25n/min
|
25n/min
|
25n/min
|
|
|
Steam
|
Consumption
|
250kg/h
|
300kg/h
|
400kg/h
|
450kg/h
|
|
|
|
Pressure
|
0.2-0.6mpa
|
0.2-0.6mpa
|
0.2-0.6mpa
|
0.2-0.6mpa
|
|
|
Compressed air
|
Consumption
|
0.2m3/min
|
0.25m3/min
|
0.3m3/min
|
0.35m3/min
|
|
|
|
Pressure
|
0.4-0.6mpa
|
0.4-0.6mpa
|
0.4-0.6mpa
|
0.4-0.6mpa
|
|
|
Environmental requirements
|
Temperature
|
20-25
|
20-25
|
20-25
|
20-25
|
|
|
|
Humidity
|
55%
|
55%
|
55%
|
55%
|
|
|
Total electric power
|
|
18kw/380v
|
18kw/380v
|
20kw/380v
|
25kw/380v
|
|
|
Length of production line
|
|
11m
|
13m
|
14m
|
17m
|
|
PACKING AND SHIPPING
PACKING
WOODEN PACKING
CONTAINER LOADING
DRIVE TO THE PORT
LADING
SHIPPING
COMPANY PROFILE
Shanghai Waifan Food Machinery manufacturing co.,ltd
Located at the forward position for china’s economic development-Shanghai chemical industrial Zone,Shanghai Waifan machinery manufacturing co.,ltd.is a comprehensive enterprise that specializes in research,development and production of food machinery,intergrating technology,industry and trade.featured by advanced technology,high quality,centralized functions and simple operation ,the automatic whole-set equipment for chocolate,candy,biscuit,cake,swiss roll,cookie,bread,flaky pastry,moon cake and etc.produced by our factory is the ideal new type food machinery chosen by users.The products are sold well throughout China and exported all over the world.
Design
Produce
Adjust
SERVICE TEAM
CUSTOMER PHOTOS
CERTIFICATES
FAQ
Q1：Where is your factory?
A1：Our factory in No. 300,Xinnuo road, Fengxian District,Shanghai, China.
A1：Our factory in No. 300,Xinnuo road, Fengxian District,Shanghai, China.
Q2： How is the payment?
A2：We accept 30% T/T deposit before production and 70% T/T balance before shipment.And L/C
A2：We accept 30% T/T deposit before production and 70% T/T balance before shipment.And L/C
Q3：How long is your guarantee time?
A3：We have a guarantee period of 12 months from the date of shipment.
A3：We have a guarantee period of 12 months from the date of shipment.
Q4： What information does the quotation require?
A4：Which kind of cookie do you make? Pictures of your snacks if you have.Which production capacity do you prefer?
A4：Which kind of cookie do you make? Pictures of your snacks if you have.Which production capacity do you prefer?
