Quick Details
-
Material:
-
Steel
-
Brand Name:
-
Gooxi
-
Place of Origin:
-
Guangdong, China
-
Chassis:
-
Rackmount
-
Form factor:
-
6U Rackmount chassis
-
PSU Form Factor:
-
1+1 Redundat
-
SGPIO:
-
Support
-
HDD Backplane:
-
12Gb/s SAS Expander Backplane
-
Cooling fans:
-
3x12038 hotswap fans
-
Hotswap Fans:
-
support
-
Top cover Tool-less:
-
support
-
Motherboard Supporting:
-
EEB(12*13)/CEB(12*10.5)/ATX(12*9.5)/Micro ATX
-
Drive Bays:
-
48*3.5''HDD
Quick Details
-
Application:
-
Server
-
Type:
-
Rack
-
Form Factor:
-
ATX
-
Material:
-
Steel
-
Brand Name:
-
Gooxi
-
Place of Origin:
-
Guangdong, China
-
Chassis:
-
Rackmount
-
Form factor:
-
6U Rackmount chassis
-
PSU Form Factor:
-
1+1 Redundat
-
SGPIO:
-
Support
-
HDD Backplane:
-
12Gb/s SAS Expander Backplane
-
Cooling fans:
-
3x12038 hotswap fans
-
Hotswap Fans:
-
support
-
Top cover Tool-less:
-
support
-
Motherboard Supporting:
-
EEB(12*13)/CEB(12*10.5)/ATX(12*9.5)/Micro ATX
-
Drive Bays:
-
48*3.5''HDD
Introduce
Safe and stable
EEB(12*13)/CEB(12*10.5)/ATX(12*9.5)/Micro ATX / Supports SGPIO; compatible with SAS3.0/SATA3.0 hard drive
* Flexible motherboard matching
EEB(12*13)/CEB(12*10.5)/ATX(12*9.5)/Micro ATX / Supports SGPIO; compatible with SAS3.0/SATA3.0 hard drive
* Excellent heat-dissipation performance
* High-rate transmission backplane
Product Paramenters
|
Chassis Height
|
6U
|
|
Compatible Motherboard
|
EEB(12*13)/CEB(12*10.5)/ATX(12*9.5)/Micro ATX
|
|
Power Type
|
Single power or 1+1 redundant power supply
|
|
Backplane
|
12Gb/s active backplane
|
|
Hard Drive Bay
|
Supports SGPIO; compatible with SAS3.0/SATA3.0 hard drives, front 36x 3.5” (or 2.5”) hot-swap hard drives, 12x 3.5” (or 2.5”)
hot-swap hard drives in the rear (SAS 3.0/SATA3.0); 2x built-in 2.5" SAS3.0/SATA 3.0 hot-swap hard drives, optional rear 2x 2.5" SAS3.0/SATA3.0 hot-swap hard drives |
|
HDD Shockproof
|
The hard drive rack adopts EMI spring design, unique shockproof fan design, reduces the resonance between the fan and the hard
disk, and does not affect the hard drive I/O speed |
|
System Fan
|
Supports intelligent-temperature control, 12x 8038 hot-swap fans
|
|
Expansion Slot
|
7x half-height PCIe expansion card slots
|
|
Security
|
Locked upper cover of chassis
|
|
Front Panel Control
|
2 USB3.0, 1 power switch, 1 reset button, 1 power indicator, 1 hard disk indicator, 2 network indicators
|
|
Slide Rail
|
Optional
|
|
Air Duct
|
Optional
|
|
Front Mask
|
Optional
|
|
Product Material
|
Imported SGCC (galvanized steel sheet), ABS panel and perforated mesh
|
|
Chassis Size
|
695mm*433mm*265.4mm (D* W* H)
|
|
Chassis Gross Weight
|
50kg（Net weight）/ 53kg（Gross weight）
|
|
Package Size
|
975mm*591mm*401mm (D* W* H）
|
|
Metal Thickness
|
1mm SGCC
|
|
Chassis Dimensions
|
670*444*132mm (DxWxH)
|
|
Net Weight
|
15.5 KG
|
|
Carton Dimensions
|
902*591*273mm (DxWxH）
|
|
Gross Weight
|
21.5 KG
|
|
Certification
|
CE, FCC, RoHS
|
