Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
CA100A
-
Model Number:
-
CA100A
-
Product name:
-
Car gps speed limiter
-
Working Temperature:
-
-40°C to +85°C
-
Communication Module:
-
GSM
-
Processing Chip:
-
ARM
-
Speed limit Scope:
-
40-120KM/H
-
Speed Limit Deviation:
-
±5KM/H
-
Mechanical Bearing Capacity:
-
400N
-
Usage:
-
For all vehicle
-
Weight:
-
2.4KG
-
Size:
-
10.5*8.3*3.1 CM
Quick Details
-
Positioning Mode:
-
GPS
-
Function:
-
ACC Detection, Geofence
-
Warranty:
-
2 year
-
Place of Origin:
-
China
-
Brand Name:
-
CA100A
-
Model Number:
-
CA100A
-
Product name:
-
Car gps speed limiter
-
Working Temperature:
-
-40°C to +85°C
-
Communication Module:
-
GSM
-
Processing Chip:
-
ARM
-
Speed limit Scope:
-
40-120KM/H
-
Speed Limit Deviation:
-
±5KM/H
-
Mechanical Bearing Capacity:
-
400N
-
Usage:
-
For all vehicle
-
Weight:
-
2.4KG
-
Size:
-
10.5*8.3*3.1 CM
Ethiopia GPS Speed Limiter With Standard ES6413 for Vehicles
Speed limiter device shall be so designed, constructed and assembled and fitted to the vehicle to make it maximum tamper proof and fail safe, against various factors such as disconnection / failure of various components e.g. power supply, speed sensor, mechanical actuator system, linkages etc. or any unauthorized modification and adjustment to the system.
Product Function:
| Limiting Mode | Limiting Function Introduction |
| extension functions | 1) Mainly used in Kenya to control vehicle speed and further expand the market for auto speed limiters in Ethiopia. |
| 2) Vehicle speed pulse detection; it is a speed limiter and also a GPS tracker, surpassing the traditional GPS tracker. | |
| 3) One channel high input detection, one channel low input detection; | |
| 4) One channel power-off control output, one channel oil-off control output; | |
| 5) Three channels of analog input. One is used for fuel consumption data detection, another is used for the ordinary analog voltage detection, the third one is for standby; | |
| 6) One channel RS232 defining interface; | |
| 7) One channel RS232/RS458 compatible interface; | |
| 8) The (G-SENSOR) acceleration sensor interface reserved, can open for some customer need. | |
| Differentiate Road Section Intelligent Speed Limiting | Limit the highest vehicle speed according to the current road speed limit value.Such as: if the current road speed limit value is 80 Km/h,the product can control the highest vehicle speed is within 0 ~ 80 Km/h. If the road limit value is 100 Km/h,the product can control the vehicle speed keep within 100 Km/h. |
| Differentiate Time Intelligent Speed Limiting | Limit the highest vehicle speed according to different time period . Such as: if you set the highest driving speed as 50Km/h from 2.00-5:00, and 80Km/h for the other time period. So this product can control the vehicle highest speed as 50Km/h from 2.00-5:00, and 80Km/h for the other time period as your order. |
| Differentiate Vehicle Type Intelligent Speed Limiting | Limit the highest vehicle speed according to different vehicle type. |
| Such as: for high speed compact car ,limit within 120Km/h; for large vehicle, limit within 100Km/h; for dangerous goods transporter, limit within 60Km/h. | |
| Differentiate Road Type Intelligent Speed Limiting | Limit the highest vehicle speed according to different road type. |
| Such as: on high-speed road, speed limit within 120 100Km/h; for fast road, speed limit within 100 Km/h, State Road 60Km/h, county road limit 50Km/h, this product according to road speed limit. | |
| Fixed Highest Speed Limiting | Can set only one or two highest driving speed value for the vehicle. Such as: According to the government regulations, some vehicle should not driving over 100Km/h(or any other appointed speed), the product can control the vehicle keep driving within 100Km/h(or any other appointed speed) |
| Note | All the intelligent speed limit function need platform support, it means your platform must have a database contains the speed limit value of each road ,if not , we can only supply the fixed highest speed limiter for you, it means that we can only set one or two high speed limit vale in this product. |
General requirements:
- Speed limiter devices shall have a built in / integrated GPS.
- Speed limiter devices shall be designed, constructed, assembled and fitted to the vehicle that it will perform satisfactorily, despite the vibrations and temperature to which it may be subjected.
- Speed limiter devices shall be calibrated and maintained in a good working order; and capable to limit the speed of a vehicle at the set speed as stipulated by the regulatory body.
- The device shall support hand held portable printer (blue-tooths, WiFi, etc) enabled
- The speed limiter function or road speed limiter shall not interfere with the brake system of the vehicle.
- The speed limiter function or road speed limiter shall be EMCcompatible or shall have Anti-Jammer mechanism.
Installation Brief:
This product is applicable for the widely used EFI vehicles and the old cable-drawing type oil injection vehicles.
For the old cable-drawing oil injection vehicles,we need add a actuator to realize the speed limit function. We connect the steel cable of the actuator to the vehicle throttle drawing cable from the opposite side, to form a counter force. When the vehicle is over speed, the the steel cable of the actuator will draw the vehicle throttle drawing cable from the opposite side, thus the throttle valve mouth will get smaller, to realize the compulsive speed limit function.
For EFI vehicle, the limiter will simulate the voltage value of the throttle sensor, when the vehicle is over speed, The limiter will give ECU a idle voltage value, ECU willcontrol the throttle according to this voltage value. Whenthe vehicleis over speed,The limiter will give ECU a idle voltage value, ECU will control the throttle according to this voltage value. When the vehicle is in normal driving state(not over speed), the throttle sensor will give ECU normal driving voltage, let the vehicle keeping normal driving.
