Quick Details
-
Brand Name:
-
Holykell
-
Model Number:
-
PS300
-
Max. Current:
-
20mA
-
Max. Working Pressure:
-
100MPa
-
Pressure Range:
-
-1 Bar-1 Bar; 0-0.1 Bar.....1000 Bar
-
Output:
-
4-20mA
-
Power Supply:
-
12~36 V DC
-
Switch type:
-
PNP, NPN optional
-
Accuracy:
-
0.25%F.S, 0.5%F.S
-
Pressure connect port:
-
G1/4''male, G1/2''male, 1/8''NPT male, 1/4''NPT male (by customized)
-
Safe Overload:
-
150% F.S.(standard)
-
Burst Pressure:
-
Burst Pressure
-
Mechanical vibration:
-
±20g
-
Response time:
-
≤5ms
Quick Details
-
Whether the smart:
-
Yes
-
Max. Voltage:
-
36VDC
-
Place of Origin:
-
Hunan, China
-
Brand Name:
-
Holykell
-
Model Number:
-
PS300
-
Max. Current:
-
20mA
-
Max. Working Pressure:
-
100MPa
-
Pressure Range:
-
-1 Bar-1 Bar; 0-0.1 Bar.....1000 Bar
-
Output:
-
4-20mA
-
Power Supply:
-
12~36 V DC
-
Switch type:
-
PNP, NPN optional
-
Accuracy:
-
0.25%F.S, 0.5%F.S
-
Pressure connect port:
-
G1/4''male, G1/2''male, 1/8''NPT male, 1/4''NPT male (by customized)
-
Safe Overload:
-
150% F.S.(standard)
-
Burst Pressure:
-
Burst Pressure
-
Mechanical vibration:
-
±20g
-
Response time:
-
≤5ms
|
Pressure Range
|
-1 Bar-1 Bar; 0-0.1 Bar.....1000 Bar
|
|
Accuracy
|
±0.25%F.S， ±0.5%F.S
|
|
Output
|
4~20mA or RS485
|
|
Pressure connect port
|
G1/4’’male, G1/2’’male
|
|
Pressure Type
|
Gauge pressure; Absolute pressure; Sealed gauge pressure; Negative pressure optional.
|
|
Safe Overload
|
150% F.S.(standard)
|
|
Burst Pressure
|
300% F.S. (standard)
|
|
Display Units Accuracy
|
≤ ±0.1%F.S
|
|
Response time
|
≤5ms
|
FAQ
Q:What kind of products do you offer ?
A:We supply pressure sensor, level sensor, flow meter and digital controllers. Main market is European countries, American, the Middle East and Asia. Certificates are international ones.
Q:Could I get samples?
A:Yes,we have materials in stock to help you to get the samples as soon as we can.
Q:How about the quality of the magnets?
A:We have the certification of ISO, Europe standard ATEX, TUV-CE and ROSH,we could send the certification test of our company to you.
Q:Could you provide me the shortest lead time?
A:We have materials in our stock,if you really need,you can tell us and we will try our best to satisfy you.
Q:Could I visit your factory?
A:Of course,if you need we will help you to visit our factory.
Q: How can I get the quotation or send my inquiry to?
A: Send your inquiry to us by the inquiry from on the right-side or the bottom of this page.
