Quick Details
-
Product name:
-
Home Solar Energy Storage System Battery
-
Capacity:
-
10.24KWH
-
Cycle life:
-
6000+times
-
Warranty:
-
10years
-
Nominal Voltage:
-
204.8V
-
Keywords:
-
Solar Home Power System
-
Battery Size:
-
650/260/905mm
-
Protection:
-
IP65 Protection
-
OEM/ODM:
-
Accepatable
-
Brand name:
-
FX POWER
Quick Details
-
Model Number:
-
FX-10kwh
-
Brand Name:
-
FX POWER
-
Place of Origin:
-
Zhejiang, China
-
Product name:
-
Home Solar Energy Storage System Battery
-
Capacity:
-
10.24KWH
-
Cycle life:
-
6000+times
-
Warranty:
-
10years
-
Nominal Voltage:
-
204.8V
-
Keywords:
-
Solar Home Power System
-
Battery Size:
-
650/260/905mm
-
Protection:
-
IP65 Protection
-
OEM/ODM:
-
Accepatable
-
Brand name:
-
FX POWER
|
Datasheet
|
ARK7.6H
|
ARK10.2H
|
ARK 12.8H
|
ARK15.3H
|
ARK17.9H
|
ARK23.0H
|
ARK25.6H
|
||||||
|
Energy Capacity
|
7.68kwh
|
10.24kwh
|
12.8kwh
|
15.36kwh
|
17.92kwh
|
20.48kwh
|
23.04kwh
|
||||||
|
Usable Capacity
|
6.9kwh
|
9.21kwh
|
11.52kwh
|
13.81kwh
|
16.12kwh
|
18.43kwh
|
20.73kwh
|
||||||
|
Nornimal Voltage
|
153.6V
|
204.8V
|
256V
|
307.2V
|
358.4V
|
409.6V
|
460.8V
|
||||||
|
Operating Voltage Range
|
|
188.8-227.2V
|
236-
284V
|
283.2-397.6V
|
330.4-397.6V
|
377.6-454.4V
|
424.8-511.2V
|
||||||
|
Dimension
(W/D/H)
|
650/260/725mm
|
650/260/905mm
|
650/260/1085mm
|
650/260/1265mm
|
650/260/1145mm
|
650/260/1625mm
|
650/260/1805nn
|
||||||
|
Weight
|
91kg
|
118kg
|
145kg
|
172kg
|
199kg
|
226kg
|
253kg
|
||||||
|
Battery Type
|
|
|
|
|
|
|
|
||||||
|
Standard Charge/
Discharge Current
|
25A/0.5C
|
|
|
|
|
|
|
||||||
|
IP Protection
|
|
|
|
|
|
|
|
||||||
|
Warranty
|
10 years
|
|
|
|
|
|
|
||||||
