Quick Details
-
Model Number:
-
APR323
-
Thickness:
-
1-5mm, 2,3,4,5mm
-
Size:
-
50m/roll, 200~500MM*50M
-
Product name:
-
Strip PVC curtain
-
COLOR:
-
Blue,Green,etc according to your request
-
Tempreture:
-
-50 celsius degree to +50 celsius degree
-
Feature:
-
Freezer
-
MOQ:
-
500KG
Quick Details
-
Processing Service:
-
Cutting, Moulding
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
APR
-
Model Number:
-
APR323
-
Thickness:
-
1-5mm, 2,3,4,5mm
-
Size:
-
50m/roll, 200~500MM*50M
-
Product name:
-
Strip PVC curtain
-
COLOR:
-
Blue,Green,etc according to your request
-
Tempreture:
-
-50 celsius degree to +50 celsius degree
-
Feature:
-
Freezer
-
MOQ:
-
500KG
Specifications
|
Item |
Unit |
Typical Vale |
|
|
Product name |
PVC Strip Curtain |
||
|
Material |
PVC Resin |
||
|
Color |
Standard Clear/Blue/Green/Orange/Yellow/Red/Dark Green/Black/Blue/Amber etc |
||
|
Pattern |
Smooth/Single ribbed/Double ribbed |
||
|
Common Size |
-200mm × 2mm/3mm/4mm × 50m/Roll -300mm × 2mm/3mm/4mm × 50m/Roll -400mm × 2mm/3mm/4mm × 50m/Roll Customized |
||
|
Type |
Welding strip curtains; Standard clear &door curtains; Polar door &curtains; Anti-Insect door &curtains; Anti-static door &curtains; Anti-ultraviolet door &curtains |
||
|
Effect ion |
Transparent/Translucent/Opaque |
||
|
Operating Temp. |
Paraffin |
-5 ℃ ~60 ℃ |
|
|
DOP/DOTP |
-40 ℃ ~60 ℃ |
||
|
Feature |
Cold resistance, Energy Saving, Anti-Insect , Anti-Static, UV-Proof, etc |
||
|
Where to Use |
- Industrial flexible doors; - Partitions, Protective screens, Machine covers; - Storage door way; etc |
||
|
Packages |
Each roll will be packed by PVC shrink film or woven bag, carton, pallet |
||
|
Hanger System |
Galvanized Steel or Stainless Steel Material |
||
|
Performance Text |
Unit |
Standard Formula |
Cold Formula |
Super Polar Curtain |
|
Softness A Hardness |
/ |
75+-5 |
65+-5 |
65+-5 |
|
Brittle Point |
Degrees. C |
Approx. -35 |
Approx. -45 |
Approx. -45 |
|
Falling Ball Test |
Degrees. C |
-20 No Break |
-40 No Break |
-50 No Break |
|
Flexibility |
Degrees C |
-20 No Break |
-40 Bo Break |
-50 No Break |
|
Water Absorption |
% |
0.20% |
0.20% |
0.20% |
|
Tensile Stress |
% |
340 |
420 |
420 |
|
Flammability |
0 |
Inflammable |
Inflammable |
Inflammable |
|
Airborne Insulation |
0 |
~35dB |
~35dB |
~35dB |
|
Rupture Resistance |
N/mm |
>5 |
>2 |
>2 |
|
Light Transmission |
|
>80 |
>80 |
>80 |
Feature
1.PVC Strip Curtain Excellent Anti-slip performance, Good Abrasion Resistance, Good water-proof.
2.PVC Strip Curtain Non-Laminated, producted by extrusion Technology, never cracking, No bubbles, no impurities
3.PVC Strip Curtain Provides a cost effective insulating barrier which maintains the preferred temperature, and reduces heat or cold air loss.
4.PVC Strip Curtain protects from dust, noise, pests, spray, smoke and keeps the atmosphere hygiene.
5.PVC strip curtain Outstanding clarity and transparency ensures optimum safety for both personnel and mobile traffic operating in busy access areas
6.PVC strip curtain Durable, non-flammable easily ,
Application
Freezer, cold warehouse, ice factory, warehouse industry, distribution center, food factory, feed factory, chemical factory. pharmaceutical factory, electronic factory,
machinery factory, welding factory, fire prevention factory, printing factory, asepsis room, computer room, office, supermarket, fresh market, restaurant kitchen, etc.
We can produce:
1. Room temperature and low temperature
2. Flat and ribbed
3.Super transparent and translucent
4. Anti-ultraviolet/anti-static/anti-cold
5. Width:1.5-180cm
