Quick Details
-
Weight (KG):
-
2000 kg
-
Rated Loading Capacity(kg):
-
2000
-
Max Lifting Speed (Full load):
-
400
-
Fork Lifting Height(mm):
-
3000
-
Length (Including Fork):
-
3605
-
Front Overhang(mm):
-
451
-
Engine Speed At Rated Power:
-
2500
-
Variable speed form:
-
Mechanical / Hydraulic
-
Max Driving Speed:
-
17/19
-
Load Center Distance(mm):
-
500
-
Rear Wheel Track(mm):
-
970
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
TAVOL
-
Weight (KG):
-
2000 kg
-
Rated Loading Capacity(kg):
-
2000
-
Max Lifting Speed (Full load):
-
400
-
Fork Lifting Height(mm):
-
3000
-
Length (Including Fork):
-
3605
-
Front Overhang(mm):
-
451
-
Engine Speed At Rated Power:
-
2500
-
Variable speed form:
-
Mechanical / Hydraulic
-
Max Driving Speed:
-
17/19
-
Load Center Distance(mm):
-
500
-
Rear Wheel Track(mm):
-
970
Forklifts are industrial handling vehicles, which refer to various wheeled handling vehicles used for loading, unloading, stacking, and short distance transportation of palletized goods. The International Organization for Standardization ISO/TC110 is referred to as industrial vehicles. Commonly used for the transportation of large items in storage, usually driven by fuel engines or batteries.
The technical parameters of a forklift are used to indicate its structural characteristics and working performance. The main technical parameters include: rated lifting capacity, load center distance, maximum lifting height, gantry inclination angle, maximum driving speed, minimum turning radius, minimum ground clearance, wheelbase, wheelbase, etc.
Specification
|
Model
|
CPC20/ CPCD20
|
CPC25/ CPCD25
|
CPC30/ CPCD30
|
CPC35/ CPCD35
|
CPC40/CPCD40
|
CPCD50
|
|
Rated Loading Capacity(kg)
|
2000
|
2500
|
3200
|
3600
|
4000
|
5000
|
|
Load Center Distance(mm)
|
500
|
500
|
500
|
500
|
500
|
500
|
|
Max Lifting Speed (Full load)(mm/h)
|
400
|
400
|
475
|
450
|
390
|
375
|
|
Max Driving Speed (Empty/Full load)(km/h)
|
17/19
|
17/19
|
18/20
|
18/20
|
18/20
|
20/24
|
|
Fork Lifting Height(mm)
|
3000
|
3000
|
3000
|
3000
|
3000
|
3000
|
|
Mast Tilt Angle (Forward and Backward)
|
6°/12°
|
6°/12°
|
6°/12°
|
6°/12°
|
6°/12°
|
6°/12°
|
|
Min. Turning Radius(mm)
|
2450
|
2450
|
2530
|
2540
|
2720
|
3000
|
|
Min. Ground Clearance(mm)
|
110
|
110
|
135
|
135
|
145
|
170
|
|
Length (Including Fork)(mm)
|
3605
|
3605
|
3970
|
4000
|
4100
|
4350
|
|
Width(mm)
|
1160
|
1160
|
1230
|
1230
|
1230
|
1400
|
|
Height From Ground to Overhead Guard(mm)
|
2095
|
2095
|
2105
|
2105
|
2115
|
2330
|
|
Front Overhang(mm)
|
451
|
451
|
465
|
465
|
465
|
585
|
|
Wheel Base(mm)
|
1640
|
1640
|
1775
|
1775
|
1900
|
2150
|
|
Front Wheel Track(mm)
|
970
|
970
|
1000
|
1000
|
1060
|
1180
|
|
Rear Wheel Track(mm)
|
970
|
970
|
970
|
970
|
970
|
1190
|
|
Front Wheel Tyre
|
7.00-12
|
7.00-12
|
28*9-15
|
25*9-15
|
250-15
|
300-15
|
|
Rear Wheel Tyre
|
6.00-9
|
6.00-9
|
6.50-10
|
6.50-10
|
6.50-10
|
7.00-12
|
|
Self Weight(kg)
|
3320
|
3600
|
4250/4290
|
4660/4700
|
4810/4850
|
6800
|
|
Standard Fork Length(mm)
|
1070
|
1070
|
1220
|
1220
|
1220
|
1220
|
Certifications
Packing & Delivery
----One set by 1*20/40 Container
————According to different model
Customized
Different Stages Full Free Mast
Side-shift
Different Engine.
