Quick Details
-
Place of Origin:
-
Shandong, China
-
Dimension(Long * Breadth * High):
-
6450*2490*3120mm
-
Machine Weight:
-
10050 kg
-
Bucket capacity:
-
1.2m³
-
Wheel base:
-
2335
-
Wheel tread:
-
2139
-
Displacement:
-
4.8L
-
Rated speed:
-
2200(r/min)
-
Max. Torque:
-
400(N.M)
-
Working pump displacement:
-
63ml/r
-
Working pump pressure:
-
20Mpa
-
Hydraulic oil tank:
-
125
-
Fuel tank:
-
125
Quick Details
-
Engine Brand:
-
YC4A105Z-T20
-
Power:
-
75kw
-
Brand Name:
-
Tonlita
-
Place of Origin:
-
Shandong, China
-
Dimension(Long * Breadth * High):
-
6450*2490*3120mm
-
Machine Weight:
-
10050 kg
-
Bucket capacity:
-
1.2m³
-
Wheel base:
-
2335
-
Wheel tread:
-
2139
-
Displacement:
-
4.8L
-
Rated speed:
-
2200(r/min)
-
Max. Torque:
-
400(N.M)
-
Working pump displacement:
-
63ml/r
-
Working pump pressure:
-
20Mpa
-
Hydraulic oil tank:
-
125
-
Fuel tank:
-
125
Product Dispiay
|
|
|
|
|
Total length(bucket at ground
|
6450±80mm
|
|
|
Total width
|
2490±20mm
|
|
|
Bucket width
|
2500mm
|
|
|
Total height (cabin top)
|
3120±10mm
|
|
|
Total height (digging boom top)
|
3940 ±20mm
|
|
|
Wheel base
|
2335±10 mm
|
|
|
Wheel tread
|
2139 ±10mm
|
|
|
Load main technical parameter
|
|
|
|
Rated load
|
2500KG
|
|
|
Operating weight
|
10050kg
|
|
|
Rated bucket capacity
|
1.2m³
|
|
|
Max. Dumping height (41o dumping angle)
|
3050±50 mm
|
|
|
Dumping distance
|
870±20 mm
|
|
|
Digging main technical parameters
|
|
|
|
Rated digging bucket capacity
|
0.3m³
|
|
|
Max. Digging depth
|
3820±20 mm
|
|
|
Max. Digging radius
|
5345±20mm
|
|
|
Max. Loading height
|
3740±20mm
|
|
|
Max. Digging force
|
5100kgf
|
|
|
Max.Digging height
|
5470 ±20mm
|
|
|
Lifting force at Max. Digging radius
|
1220kg
|
|
|
Engine
|
|
|
|
Engine model
|
YC4A105Z-T20
|
|
|
Cooling type
|
Water cooling)
|
|
|
Rated power
|
75 (kW)
|
|
|
Displacement
|
4.8(L)
|
|
|
Rated speed
|
2200(r/min)
|
|
|
Max. Torque
|
400(N.M)
|
|
|
Manufacturer
|
YUCHAI
|
|
|
Hydraulic system
|
|
|
|
Working pump displacement
|
63ml/r
|
|
|
Working pump pressure
|
20Mpa
|
|
|
Diverter model
|
BZZ5-250
|
|
|
Oil capacity
|
|
|
|
Hydraulic oil tank
|
125
|
|
|
Fuel tank
|
125
|
|
Attachments
Shipping&Packaging
Our Company
Factory Inturduction
FAQ
Are you a manufacturer or Trader ?
We are a professional manufacture , we have our own R&D team and sales team, we provide one-stop service.
What is your payment term ?
We accept T/T, L/C at sight, Western Union, Paypal etc.
How long is the validity of quotation ?
Generally, our price is valid within 15 days from the date of quotation .The price will be adjusted appropriately according to the price fluctuation of raw material and changes in market .
What is your delivery time ?
Usually, we make merchandise inventory, if we have the products in stock, the delivery time is 5-10 days after receiving the
deposit.
If we don't have the products in stock, we will arrange the production right now, the delivery time will be 20-30 days,It depend on the order quantity.
Do you provide OEM/ODM Service ?
Yes, offer us necessary information, we provide custom-make service to meet different needs of global clients with different budgets.
Do you have CE certificate ?
Yes, most of our products have the CE certificate.
How can we ensure quality?
The final inspection is always carried out before shipment.
How to install the equipment after purchasing ?
We will provide professional installation video to illustrate.Also provide manual.
Do you offer a guarantee?
We are a professional manufacture , we have our own R&D team and sales team, we provide one-stop service.
What is your payment term ?
We accept T/T, L/C at sight, Western Union, Paypal etc.
How long is the validity of quotation ?
Generally, our price is valid within 15 days from the date of quotation .The price will be adjusted appropriately according to the price fluctuation of raw material and changes in market .
What is your delivery time ?
Usually, we make merchandise inventory, if we have the products in stock, the delivery time is 5-10 days after receiving the
deposit.
If we don't have the products in stock, we will arrange the production right now, the delivery time will be 20-30 days,It depend on the order quantity.
Do you provide OEM/ODM Service ?
Yes, offer us necessary information, we provide custom-make service to meet different needs of global clients with different budgets.
Do you have CE certificate ?
Yes, most of our products have the CE certificate.
How can we ensure quality?
The final inspection is always carried out before shipment.
How to install the equipment after purchasing ?
We will provide professional installation video to illustrate.Also provide manual.
Do you offer a guarantee?
Yes, we guarantee our product for one year.
Provide after-sales service support.
