Quick Details
-
Brand Name:
-
TIANBO METAL
-
Model Number:
-
TI-01
-
Application:
-
Industry
-
Technique:
-
Forged
-
Grade:
-
Pure Titanium
-
Shape:
-
block
-
Material:
-
Gr.1,Gr.2,6Al4V ELI,Gr7,Gr9 etc.
-
Standard:
-
ASTM B348, B381,B265
-
Product Name:
-
titanium plate
-
Keyword:
-
titanium block
-
Coating:
-
Ru-Ir Ir-Ta Pt
-
Name:
-
titanium sheet
-
Certificate:
-
ISO 9001:2008
-
Color:
-
Titanium Original Color
-
Substrate:
-
Gr1/Gr 2 Titanium
Quick Details
-
Powder Or Not:
-
Not Powder
-
Ti Content (%):
-
99%
-
Place of Origin:
-
Shaanxi, China
-
Brand Name:
-
TIANBO METAL
-
Model Number:
-
TI-01
-
Application:
-
Industry
-
Technique:
-
Forged
-
Grade:
-
Pure Titanium
-
Shape:
-
block
-
Material:
-
Gr.1,Gr.2,6Al4V ELI,Gr7,Gr9 etc.
-
Standard:
-
ASTM B348, B381,B265
-
Product Name:
-
titanium plate
-
Keyword:
-
titanium block
-
Coating:
-
Ru-Ir Ir-Ta Pt
-
Name:
-
titanium sheet
-
Certificate:
-
ISO 9001:2008
-
Color:
-
Titanium Original Color
-
Substrate:
-
Gr1/Gr 2 Titanium
Factory Directly Sale High Purity asme sb-265 price pure titanium block and 3mm titanium plate baoji tianbo company
Dimension:
|
Grade |
Gr1,Gr2,Gr5(6Al4V),Gr7,Gr9,Gr11,Gr12,Gr23 etc. |
|
Standard |
ASTM B348, B381,B265 |
|
Features |
Titanium has the characteristics of high-strength, heat high strength, corrosion resistance, low thermal conductivity, modulus of elasticity. |
|
Applications |
Petroleum, powder industry, desalination of sea water, alkali industry, coking
|
|
Shape |
bar,tube,sheet,wire,stardard parts,drawing machined parts etc kinds of titanium products |
Chemical Composition (max, %):
|
N |
C |
H |
Fe |
O |
Al |
V |
Residules each |
Residules each |
Ti |
|
0.05 |
0.08 |
0.015 |
0.4 |
0.2 |
5.5-6.75 |
3.5-4.5 |
0.1 |
0.4 |
Balance |
Mechanical Properties (min) :
|
Tensile, Mpa |
Yield, Mpa |
Elongation, % |
|
895 |
828 |
25 |
|
|
|
The usage of various Titanium detailed description:
(1). Grade 1 can be used in the drawing parts for its good elongation and excellent corrosion-resistance.
(2).Grade 2 is used most widely in the commercially pure titani
(3).Grade 3 is almost used in pressure,vessel.
(4).Grade 4 can be used in some fittings parts and fastening pieces, but for complex shape need 300
degree celsius to form.
(5).Alloy grade 5(Ti-6Al-4V) widely used in the titanium alloys because of its comprehensive mechanical
and chemical properties.
(6).Alloy grade 7 add little palladium in cp titanium and it has the most excellent corrosion-resistance,of
course it costs higher.
(7). Alloy grade 9(Ti-3Al-2.5V) is the most widely used in the golf clubs and bicycle girders.
(8). Alloy grade 23, ELI (extra low interstitial),can be used in the medical appliance.
