Quick Details
-
Dimensions(L*W*H):
-
10*2.8*4.2m
-
Weight:
-
20000 KG
-
Print Dimension:
-
950mm
-
Print Speed:
-
200m/min
-
Printing speed:
-
260m/min
-
Material of anilox roller:
-
ceramic anilox rollers
-
Way of unwind and rewind:
-
pneumatic type
-
doctor blade:
-
chamber doctor blade
-
printing precision:
-
+-0.1mm
-
Central drum Dia.:
-
800mm
-
Camera:
-
1 pc
-
Adjusting of register:
-
electric motor+PLC touch screen
-
Heating power:
-
70kw
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
QIANGTUO
-
Voltage:
-
3P 380V 50/60HZ
-
Dimensions(L*W*H):
-
10*2.8*4.2m
-
Weight:
-
20000 KG
-
Print Dimension:
-
950mm
-
Print Speed:
-
200m/min
-
Printing speed:
-
260m/min
-
Material of anilox roller:
-
ceramic anilox rollers
-
Way of unwind and rewind:
-
pneumatic type
-
doctor blade:
-
chamber doctor blade
-
printing precision:
-
+-0.1mm
-
Central drum Dia.:
-
800mm
-
Camera:
-
1 pc
-
Adjusting of register:
-
electric motor+PLC touch screen
-
Heating power:
-
70kw
VR
Products Description
Details Images
|
Machine model
|
QTH-CI-8600 QTH-CI-8800 QTH-CI-81000 QTH-CI-81200
|
|
Max.material width
|
600mm 800mm 1000mm 1200mm
|
|
Max printing width
|
560mm 760mm 960mm 1160mm
|
|
Suitable for material
|
PAPER：15~300g/m2 NONWOVEN： 15-120G、PVC：10~120μm、OPP：10~100μm、BOPP：10~100μm、PE：15~150μm，NY：10~120μm.PET：10~100um，CPP：10~100μm
|
|
Colours
|
(8 Colours)
|
|
Printing length
|
400-1000mm
|
|
Machine speed
|
(250m/min)
|
|
printing speed
|
10-220m/min
|
|
printing precision
|
±0.1mm
|
|
Plate thickness
|
1.7mm ( if different thickness， please note us)
|
|
Central drum diameter
|
2000mm
|
Central drum
entry and exit synchro motor control
unwinder
rewinder
For 4+4 printing or 8+8 printing
Servo EPC
Heavy type chamber doctor blade
Hydraulic auto unloading+Surface roll rewinding +reduce motor
