Quick Details
-
Warranty:
-
Other
-
Brand Name:
-
Mars Rock
-
Model Number:
-
85mA 6V
-
Place of Origin:
-
Fujian, China
-
Panel Dimensions:
-
193*56*3.2mm
-
MODEL:
-
85mA 6V
-
Voltage:
-
6V
-
Current:
-
85mA
-
Power:
-
0.51W
-
Raw Material:
-
Amorphous
-
Product size:
-
193*56*3.2mm
-
Test condition:
-
100000LUX (AM1.5 solar spectrum, irradiance 100mW/cm²)
-
Efficiency:
-
11-13%
-
Weight:
-
0.05kg/pcs
-
Certificate:
-
CE FC ROHS
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
Amorphous
-
Panel Efficiency:
-
22-23%
-
Warranty:
-
Other
-
Brand Name:
-
Mars Rock
-
Model Number:
-
85mA 6V
-
Place of Origin:
-
Fujian, China
-
Panel Dimensions:
-
193*56*3.2mm
-
MODEL:
-
85mA 6V
-
Voltage:
-
6V
-
Current:
-
85mA
-
Power:
-
0.51W
-
Raw Material:
-
Amorphous
-
Product size:
-
193*56*3.2mm
-
Test condition:
-
100000LUX (AM1.5 solar spectrum, irradiance 100mW/cm²)
-
Efficiency:
-
11-13%
-
Weight:
-
0.05kg/pcs
-
Certificate:
-
CE FC ROHS
Products Description
Features
1)Copes easily with deviceʼs required drive voltage
Since multiple cells can be simultaneously connected in a series when the solar cells are formed, unlike the fabrication technique used with crystalline silicon solar cells in which multiple solar cells are severed and connected, it is easy to create cells with a variety of voltages.
2)Variety of shapes and forms
The methods used in amorphous silicon films have special features that allow other substrates, such as stainless steel or plastic films, to be used instead of customary glass substrates. This means that previously unknown solar cells can also be created, including solar cells that are round, square, or any other complex shape or solar cells that can even be bent. It is also possible to create areas in these solar cells that just consist of transparent glass by etching.
3)High sensitivity within visible light spectrum
The human eye is sensitive to light from a range of about 400 to 700 nm wavelengths.
Since amorphous silicon solar cells are sensitive to light with essentially the same wavelengths, they can also be used as visible light sensors.
Specification
|
MODEL
|
85mA 6V
|
|
Voltage
|
6V
|
|
Current
|
85mA
|
|
Power
|
0.51W
|
|
Raw Material
|
Amorphous
|
|
Produt size
|
193*56*3.2MM
|
|
Shape
|
Rectangular
|
|
Place of Origin
|
China-Fujian
|
|
Test condition
|
100000LUX (AM1.5 solar spectrum, irradiance 100mW/cm², temperature
|
|
Efficiency
|
11-13%
|
|
Weight
|
0.05kg/pcs
|
|
Color
|
Brown
|
|
Certificate
|
CE FC ROHS
|
Please note that due to the frequent advancements in technology, the provided parameter table and pictures are solely for
reference purposes. It is normal to expect slight variations between the actual product and the depicted images and
specifications. Kindly consider the actual product as the prevailing standard.
reference purposes. It is normal to expect slight variations between the actual product and the depicted images and
specifications. Kindly consider the actual product as the prevailing standard.
1)Indoor use A-Si solar cell, excellent sensitivity under low and medium illumination, Provide good charging or direct power under low light and indoor lighting conditions;
2)Superior performance under week light condition,10%-15% higher actual annual power generation per nominal watt power;
3)lower temperature coefficient, better performance under high temperature condition;
4)Customized shape & different size available. High translucent glass which is can be made into borderless Solar Panel;
5)1.1mm ultra-thin thickness can be easily embedded into plastic holder;
6)Glass substrate which can be used in harsh environmental conditions with waterproof and scratch-resistant, UV protection. So it is one type of Durable and durable, long service life, anti-corrosion solar panel.
Application
●Wristwatches / Clocks / Wall clocks
●Calculators
● Energy-harvesting equipment
●Wireless sensor networks / RFID tags / RF remote controls for digital home appliances, etc.
●Power sources for multiple cards attached to displays
●Power sources of wearable terminals
●Toys
●e-books
●Garden lights, sensor lights, LED blinkers (curbstone markers, etc.)
●Car accessories and battery chargers
●Security devices
●Power sources for other electric equipment and digital displays
●Reduction of battery replacements and extension of battery life for appliances using dry cells and coin batteries
●The power supply for human body sensors, the power supply for temperature & humidity sensors
●Calculators
● Energy-harvesting equipment
●Wireless sensor networks / RFID tags / RF remote controls for digital home appliances, etc.
●Power sources for multiple cards attached to displays
●Power sources of wearable terminals
●Toys
●e-books
●Garden lights, sensor lights, LED blinkers (curbstone markers, etc.)
●Car accessories and battery chargers
●Security devices
●Power sources for other electric equipment and digital displays
●Reduction of battery replacements and extension of battery life for appliances using dry cells and coin batteries
●The power supply for human body sensors, the power supply for temperature & humidity sensors
