Quick Details
-
Dimension(L*W*H):
-
2*0.9*1.55M
-
Application:
-
timber mill
-
Weight (KG):
-
410 KG
-
Power (kW):
-
4-7.5
-
Max.Working Width(mm):
-
900mm, 150mm
-
Marketing Type:
-
New Product 2021
-
Core Components:
-
/
-
Product name:
-
Sawmill Portable
-
Keyword:
-
Wood Cutting Sliding Table Saw Machine
-
Function:
-
Wood Cuting
-
Application Wood:
-
Round Wood
-
Application Wood 1:
-
Hard Wood Etc
-
Cutting material:
-
Nature Wood
-
Engine:
-
Gasonlin 15HP/ 12HP
-
Max cutting length 1:
-
according to customer
Quick Details
-
Place of Origin:
-
China
-
Usage:
-
Woodworking
-
Voltage:
-
380V/50HZ
-
Dimension(L*W*H):
-
2*0.9*1.55M
-
Application:
-
timber mill
-
Weight (KG):
-
410 KG
-
Power (kW):
-
4-7.5
-
Max.Working Width(mm):
-
900mm, 150mm
-
Marketing Type:
-
New Product 2021
-
Core Components:
-
/
-
Product name:
-
Sawmill Portable
-
Keyword:
-
Wood Cutting Sliding Table Saw Machine
-
Function:
-
Wood Cuting
-
Application Wood:
-
Round Wood
-
Application Wood 1:
-
Hard Wood Etc
-
Cutting material:
-
Nature Wood
-
Engine:
-
Gasonlin 15HP/ 12HP
-
Max cutting length 1:
-
according to customer
Product Description
Feature
1.wood working machinery wood cutting bandsaw bandsaw sawmill
2.Sawmill Quick clamping lever and blade tension adjustment on the back of the machine.
3.bandsaw sawmill upper lower blade guide molded bearings improved performance extended blade life
2.Sawmill Quick clamping lever and blade tension adjustment on the back of the machine.
3.bandsaw sawmill upper lower blade guide molded bearings improved performance extended blade life
Product Parameters
|
Model
|
MG-590
|
MG-690
|
MG-800
|
|
Saw wheel diameter
|
410mm
|
410mm
|
510mm
|
|
Max Round Wood Diameter
|
590mm
|
690mm
|
900mm
|
|
Max Square Wood Width
|
530mm
|
630mm
|
830mm
|
|
Single Machinable thickness
|
150mm
|
150mm
|
200mm
|
|
Thinnest Machinable wood thickness
|
3-4mm
|
3-4mm
|
3-4mm
|
|
Standard processing length
|
3.4m(Customed length)
|
3.4m(Customed length)
|
3.4m(Customed length)
|
|
Standard weight
|
360KG
|
410kg
|
440kg
|
|
Optional power system
|
220V3KW,380V4KW
Gasoline |
220V3KW,380V5.5KW
Gasoline |
220V3KW,380V7.5KW Gasoline
|
|
Dimension
|
1700*900*1250mm
|
1800*900*1350mm
|
2000*900*1550mm
|
Detailed Images
FAQ
Q1: What’s the delivery time?
A : 5-10 work days after receiving client’s payment
Q2: What’s package?
A: wooden box packaging
Q3: Do you have any timely technology supports?
A: we have a professional technology supporting team for your timely services. We prepare the technical documents for you, also
you can contact us by telephone, online chat (googletalk, MSN, skype, yahoo…).
Q4: What’s the payment method?
A: T/T, WESTERN UNION, MONEY GRAM, ESCROW,LC...
Q5: How to ensure that I received the machine undamaged?
A: At first , our package is standard for shipping, before packing, we will confirm product undamaged, otherwise, please contact
within 2days. Because we've bought insurance for you, we or shipping company will be responsible!
