Quick Details
-
Rated Voltage:
-
36KV, 36kV
-
Tensile Strength:
-
20KN
-
Product name:
-
tension suspension Insulator
-
Usage:
-
Insulation Protection
-
Creepage distance:
-
1200mm
-
Mechanical failing load:
-
10KN
-
Stud/Bolt:
-
M20
-
Housing:
-
Polymer
-
Keywords:
-
post insulator, pin insulator
-
Certification:
-
Type test report
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
L&R
-
Model Number:
-
57-1
-
Rated Voltage:
-
36KV, 36kV
-
Tensile Strength:
-
20KN
-
Product name:
-
tension suspension Insulator
-
Usage:
-
Insulation Protection
-
Creepage distance:
-
1200mm
-
Mechanical failing load:
-
10KN
-
Stud/Bolt:
-
M20
-
Housing:
-
Polymer
-
Keywords:
-
post insulator, pin insulator
-
Certification:
-
Type test report
It has good cantilever strength, torsion, the impact of the shack and explosion-proof superior performance, reliability, insulation, light weight,
easy installation, voltage levels typically from 6 to 36 KV. Its top and bottom installed are the same as the corresponding size of porcelain
insulator,so they can be interchangeable use.
Purchase notice:
1 the specifications and pattern of the both end fitting
2 the main dimension and rate voltage
3 the colour of silicon rubber ,usually it is gray
4 other particular requirement
Technical parameters
|
ANSI CLASS |
57-1 |
57-2 |
57-3 |
57-4 |
|
Creepage 8 Distance,mm |
356 |
559 |
737 |
1015 |
|
Dry Arcing Distance,mm |
165 |
241 |
311 |
368 |
|
Cantilever S t rength, kN |
12.5 |
12.5 |
12.5 |
12.5 |
|
P
ower
Fre
q
uen
cy
|
70 |
100 |
125 |
140 |
|
Power Frequency
|
50 |
70 |
95 |
110 |
|
Cr
i
tical Impulse Flashover
|
120 |
160 |
200 |
230 |
|
T est Voltage to Ground,KV |
15 |
22 |
30 |
44 |
|
Maximum R I Y at 1000KHZ.uy |
100 |
100 |
200 |
200 |
|
Net Weight, kgs |
4.8 |
7.8 |
11.0 |
18.0 |
