Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CUMMINS
-
Model Number:
-
VCM-27.5TKA184F
-
Weight:
-
1150KG
-
Engine Model:
-
4B3.9-G1/27kw
-
Engine type:
-
4 cylinder, 4 stroke, Vertical, Direct Injection, Naturally Aspirated
-
Alternator brand:
-
Stamford Marathon Leroysomer
-
Alternator type:
-
AVR, All Copper coil, Brushless, Self-excited, Single bearing
-
Control panel:
-
Deepsea / ComAp / Harsen / Smartgen 6110
-
Max power:
-
30.3kva/24.2kw
-
Fuel Consumption at 100% load:
-
6.16 L/H
-
Fuel tank capacity:
-
10 working hours
-
Dimension(L*W*H):
-
2.2*1.0*1.3 m
Quick Details
-
Rated Voltage:
-
12V, 48V, 110V, 220V, 230V, 240V, 380v, 400V, 480V
-
Rated Current:
-
42A
-
Frequency:
-
50HZ/60HZ
-
Warranty:
-
1 Year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CUMMINS
-
Model Number:
-
VCM-27.5TKA184F
-
Weight:
-
1150KG
-
Engine Model:
-
4B3.9-G1/27kw
-
Engine type:
-
4 cylinder, 4 stroke, Vertical, Direct Injection, Naturally Aspirated
-
Alternator brand:
-
Stamford Marathon Leroysomer
-
Alternator type:
-
AVR, All Copper coil, Brushless, Self-excited, Single bearing
-
Control panel:
-
Deepsea / ComAp / Harsen / Smartgen 6110
-
Max power:
-
30.3kva/24.2kw
-
Fuel Consumption at 100% load:
-
6.16 L/H
-
Fuel tank capacity:
-
10 working hours
-
Dimension(L*W*H):
-
2.2*1.0*1.3 m
Product Description
| The Paramter of Engine | Model: | 4B3.9-G1/27kw |
| Displacement and Bore*Stroke: | 3.9 L and 102*120 mm | |
| Type | 4 Cylinder, 4 Stroke, Water cooled, Direct Injection, Electronic Governor, Vertical & Naturally Aspirated | |
| Start-up | Electric start(DC24V) | |
| The Parmter of Alternator | Model: | CP-184F/20kw |
| Type: | AVR, All Copper coil, Brushless, Self-excited and Single bearing | |
| Electrical phase connection: | 3 phase 4 wire | |
| Protection class/Insulation class: | IP23/H | |
| The Paramter of control system | Brand: | Mebay DC52D |
| High water temperature protection: | Yes | |
| High and low voltage/frequency: | Yes | |
| Low oil pressure pretection: | Yes | |
