Quick Details
-
Brand Name:
-
JHA
-
Model Number:
-
JHA-SW4024MGH
-
Place of Origin:
-
Guangdong, China
-
Interfaces:
-
4 10G SFP+Slots and 24 24 10/100/1000Mbps RJ45 ports
-
Switching Capacity:
-
128Gbps
-
Packet Forwarding Rate:
-
95.3Mpps
-
MAC Address Table:
-
32K
-
Flash memory capacity:
-
256MB
-
The memory capacity:
-
2G
-
Power Supply:
-
DC10-58V/AC 100-240V 50-60HZ
Quick Details
-
Transmission Rate:
-
10/100/1000/10000Mbps
-
Communication Mode:
-
Full-Duplex & Half-Duplex
-
Switch Capacity:
-
128G
-
Brand Name:
-
JHA
-
Model Number:
-
JHA-SW4024MGH
-
Place of Origin:
-
Guangdong, China
-
Interfaces:
-
4 10G SFP+Slots and 24 24 10/100/1000Mbps RJ45 ports
-
Switching Capacity:
-
128Gbps
-
Packet Forwarding Rate:
-
95.3Mpps
-
MAC Address Table:
-
32K
-
Flash memory capacity:
-
256MB
-
The memory capacity:
-
2G
-
Power Supply:
-
DC10-58V/AC 100-240V 50-60HZ
Detail Images
Overview
JHA-SW4024MGH series switches support Layer 3 routing protocols that include Static Routing, RIP, OSPF and VRRP, helping to build scalable, reliable networks. Multicast routing protocols such as PIM-SM and PIM-DM guarantee efficient routing for multicast groups.
JHA-SW4024MGH series switches provide 3 kinds of out-of-band management ports: RJ45 console ports, Micro-USB console ports and RJ45 out-of-band management ports. Micro-USB console ports are designed for those laptop computers which do not support the RS232 (DB9) interface. Customers can use a USB cable to manage switches through the CLI (command-line interface). The RJ45 out-of-bandmanagement port is used solely for web management, leaving the RJ45 ports free for data transmission.
JHA-SW4024MGH series switches support Layer 3 routing protocols that include Static Routing, RIP, OSPF and VRRP, helping to build scalable, reliable networks. Multicast routing protocols such as PIM-SM and PIM-DM guarantee efficient routing for multicast groups.
JHA-SW4024MGH series switches provide 3 kinds of out-of-band management ports: RJ45 console ports, Micro-USB console ports and RJ45 out-of-band management ports. Micro-USB console ports are designed for those laptop computers which do not support the RS232 (DB9) interface. Customers can use a USB cable to manage switches through the CLI (command-line interface). The RJ45 out-of-bandmanagement port is used solely for web management, leaving the RJ45 ports free for data transmission.
Product Paramenters
|
Interfaces
|
24 10/100/1000Mbps RJ45 ports and 4 10G SFP+Slots
|
|
Switching Capacity
|
128Gbps
|
|
Packet Forwarding Rate
|
95.3Mpps
|
|
MAC Address Table
|
32K
|
|
Flash memory capacity
|
256MB
|
|
The memory capacity
|
2G
|
|
Certification
|
CE, FCC
|
|
Power Supply
|
100-240V AC, 50/60Hz
|
|
Max Power Consumption
|
27W (220V/50Hz)
|
