Quick Details
-
After-sales Service Provided:
-
Online support, Field installation, commissioning and training, Video technical support, Overseas Call Centers, Return and Replacement, Shop warranty, Free spare parts, Field maintenance and repair service, Genius, Onsite Installation
-
Tank Volume:
-
18000L
-
车身尺寸:
-
11963*2496*3400
-
Place of Origin:
-
China
-
Brand Name:
-
SINOMADA
-
Horsepower:
-
240HP
Quick Details
-
Condition:
-
New
-
Emission Standard:
-
EURO 5
-
Gross Vehicle Weight:
-
25000
-
After-sales Service Provided:
-
Online support, Field installation, commissioning and training, Video technical support, Overseas Call Centers, Return and Replacement, Shop warranty, Free spare parts, Field maintenance and repair service, Genius, Onsite Installation
-
Tank Volume:
-
18000L
-
车身尺寸:
-
11963*2496*3400
-
Place of Origin:
-
China
-
Brand Name:
-
SINOMADA
-
Horsepower:
-
240HP
Specs for 6x4 18000L Vacuum sewage suction truck
|
SPECIFICATION |
||||
|
Dimension(Lx W xH) ( unloaded )( mm ) |
11963 × 2496 × 3400 |
|||
|
Loading Capacity (Ton) |
25 Ton |
|||
|
Volume of tanker (cbm) |
18 |
|||
|
Approaching angle/Departure angle ( ° ) |
16/9 |
|||
|
Overhang(front/rear) (mm) |
1500/3288 |
|||
|
Wheel base (mm) |
5825+1350 |
|||
|
Max speed ( km/h ) |
102 |
|||
|
Curb weight ( kg ) |
15500 |
|||
|
Engine(Steyr technology, made in China) |
Model |
WD615.87 , water-cooled , four strokes , 6 cylinders in line with water cooling , turbocharged and inter-cooling, directly injection |
||
|
Fuel type |
Diesel |
|||
|
Power, max ( kw/rpm ) |
290HP |
|||
|
Emission |
EUROII |
|||
|
Fuel tanker capacity ( L ) |
400L aluminum oil tank |
|||
|
Transmission |
Model |
HW19710, 10 speeds forward and 2 reverse |
||
|
Brake system |
Service brake |
Dual circuit compressed air brake |
||
|
Parking brake |
spring energy, compressed air operating on rear wheels |
|||
|
Steering system |
Model |
ZF8118 |
||
|
Front axle |
HF9 |
|||
|
Rear axle |
HC16 |
|||
|
Tire |
295/80R22.5 |
|||
