- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
JGJX
-
Fork Length:
-
1520mm
-
Fork Width:
-
140mm
-
Overall Dimensions:
-
4400*1900*2900mm
-
Weight (KG):
-
5000 kg
-
Model:
-
JG-T50A
-
Key words:
-
all terrain 4wd forklift
-
Product Type:
-
all rough terrain forklifts
-
Lifting height:
-
4m~ 6m
-
Engine:
-
supercharged engine
-
Power:
-
78kw
-
Warranty::
-
1 Year
-
Loading Capacity:
-
5000kg
-
Transmission:
-
Electronic Hydraulic Transmisson
-
Drive mode:
-
4wd
Quick Details
-
Min. Lifting Height:
-
3000mm
-
Warranty:
-
1 Year
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
JGJX
-
Fork Length:
-
1520mm
-
Fork Width:
-
140mm
-
Overall Dimensions:
-
4400*1900*2900mm
-
Weight (KG):
-
5000 kg
-
Model:
-
JG-T50A
-
Key words:
-
all terrain 4wd forklift
-
Product Type:
-
all rough terrain forklifts
-
Lifting height:
-
4m~ 6m
-
Engine:
-
supercharged engine
-
Power:
-
78kw
-
Warranty::
-
1 Year
-
Loading Capacity:
-
5000kg
-
Transmission:
-
Electronic Hydraulic Transmisson
-
Drive mode:
-
4wd
Forklift Manufacturer
Products Description
|
Model
|
T15A
|
T35A
|
T35A Short
|
|
Engine
|
Weifang490，40kw
|
Xichai/Yunnei493VP，36.8kw
|
Xichai/Yunnei493VP，36.8kw
|
|
Drive mode
|
4wd
|
4wd
|
4wd
|
|
Gearbox
|
265 torque converter
|
265 high low speed torque converter
|
265 high low speed torque converter
|
|
Axle
|
Isuzu
|
Wheel reduce
|
Wheel reduce
|
|
Tire
|
825-16
|
23.5/70-16
|
23.5/70-16
|
|
Wheelbase
|
1800mm
|
2200mm
|
1980mm
|
|
Rated lifting weight
|
1500kg
|
3500kg
|
3500kg
|
|
Rated lifting height
|
3000mm
|
3000-6000mm
|
3000-6000mm
|
|
Load center distance
|
500mm
|
600mm
|
600mm
|
|
Min. turning radius
|
2800mm
|
3500mm
|
3200mm
|
|
Max. climbing angle
|
≤35°
|
≤38°
|
≤38°
|
|
Min. ground clearance
|
250mm
|
350mm
|
350mm
|
|
Tilt of the mast,front/rear
|
10°/6°
|
10°/6°
|
10°/6°
|
|
Speed
|
30km/h
|
38km/h
|
38km/h
|
|
Max. hook traction
|
15Kn
|
25Kn
|
25Kn
|
|
Mast steel width
|
120mm
|
160mm
|
160mm
|
|
Fork length
|
1220mm
|
1220mm
|
1220mm
|
|
Machine weight
|
2800kg
|
4200kg
|
4200kg
|
|
Machine size
|
3200*1600*2300mm
|
4200*1850*2700mm
|
3800*1850*2300mm
|
|
Model
|
T35A Middle Articulated
|
CPCDY-35
|
T35A Rear Articulated
|
|
Engine
|
Xichai/Yunnei493VP，36.8kw
|
Yunnei/Quanchai495，55kw
|
Xichai/Yunnei493VP，36.8kw
|
|
Drive mode
|
4wd
|
4wd
|
4wd
|
|
Gearbox
|
265 high low speed torque converter
|
280 high low speed torque converter
|
265 high low speed torque converter
|
|
Axle
|
Wheel reduce
|
Wheel reduce
|
Wheel reduce
|
|
Tire
|
23.5/70-16
|
12-16.5
|
23.5/70-16
|
|
Wheelbase
|
1980mm
|
1697mm
|
2300mm
|
|
Rated lifting weight
|
3500kg
|
3500kg
|
3500kg
|
|
Rated lifting height
|
3000-6000mm
|
3000-6000mm
|
3000-6000mm
|
|
Load center distance
|
600mm
|
600mm
|
600mm
|
|
Min. turning radius
|
3200mm
|
2500mm
|
3200mm
|
|
Max. climbing angle
|
≤38°
|
≤38°
|
≤38°
|
|
Min. ground clearance
|
350mm
|
320mm
|
350mm
|
|
Tilt of the mast,front/rear
|
10°/6°
|
10°/8°
|
10°/8°
|
|
Speed
|
38km/h
|
35km/h
|
38km/h
|
|
Max. hook traction
|
25Kn
|
30Kn
|
25Kn
|
|
Mast steel width
|
160mm
|
160mm
|
160mm
|
|
Fork length
|
1220mm
|
1220mm
|
1220mm
|
|
Machine weight
|
4200kg
|
5500kg
|
4500kg
|
|
Machine size
|
3600*1850*2150mm
|
3200*1500*2300mm
|
3700*1850*2350mm
|
|
Model
|
T50A
|
T50A Short
|
CPCDY-50
|
|
Engine
|
Xichai/Yunnei4102，80-83kw
|
Huajie 4102
|
Yunnei4102，80kw
|
|
Drive mode
|
4wd
|
4wd
|
4wd
|
|
Gearbox
|
265 high low speed torque converter
|
265 high low speed torque converter
|
280 high low speed torque converter
|
|
Axle
|
Wheel reduce
|
Wheel reduce
|
Wheel reduce
|
|
Tire
|
16/70-24
|
16/70-20
|
12-16.5
|
|
Wheelbase
|
2400mm
|
19800mm
|
1890mm
|
|
Rated lifting weight
|
5000kg
|
5000kg
|
5000kg
|
|
Rated lifting height
|
4000-6000mm
|
3000-6000mm
|
3000-6000mm
|
|
Load center distance
|
600mm
|
600mm
|
600mm
|
|
Min. turning radius
|
3800mm
|
4200mm
|
3200mm
|
|
Max. climbing angle
|
≤38°
|
≤38°
|
≤38°
|
|
Min. ground clearance
|
380mm
|
380mm
|
350mm
|
|
Tilt of the mast,front/rear
|
10°/6°
|
10°/8°
|
10°/8°
|
|
Speed
|
45km/h
|
38km/h
|
35km/h
|
|
Max. hook traction
|
35Kn
|
35Kn
|
30Kn
|
|
Mast steel width
|
180mm
|
175mm
|
180mm
|
|
Fork length
|
1520mm
|
1220mm
|
1520mm
|
|
Machine weight
|
5500kg
|
5000kg
|
6500kg
|
|
Machine size
|
4500*1900*2850mm
|
4200*1920*2500mm
|
3500*1892*2300mm
|
|
Model
|
T60A
|
T80A
|
T100A
|
|
Engine
|
Xichai/Yuchai4105，90-103kw
|
Yuchai4108，110kw
|
WeichaiWP6 6105，92kw
|
|
Drive mode
|
4wd
|
4wd
|
4wd
|
|
Gearbox
|
280 high low speed torque converter
|
315 high low speed torque converter
|
315 high low speed torque converter
|
|
Axle
|
Wheel reduce
|
Wheel reduce
|
30
|
|
Tire
|
12R22.5(4/2)
|
17.5-25
|
17.5-25
|
|
Wheelbase
|
2400mm
|
2800mm
|
3000mm
|
|
Rated lifting weight
|
6000kg
|
8000kg
|
10000kg
|
|
Rated lifting height
|
4000-6000mm
|
4000-6000mm
|
4000-6000mm
|
|
Load center distance
|
600mm
|
800mm
|
800mm
|
|
Min. turning radius
|
4500mm
|
5500mm
|
6500mm
|
|
Max. climbing angle
|
≤38°
|
≤38°
|
≤38°
|
|
Min. ground clearance
|
380mm
|
380mm
|
380mm
|
|
Tilt of the mast,front/rear
|
10°/8°
|
10°/8°
|
10°/8°
|
|
Speed
|
45km/h
|
45km/h
|
45km/h
|
|
Max. hook traction
|
35Kn
|
55Kn
|
60Kn
|
|
Mast steel width
|
180mm
|
200mm
|
220mm
|
|
Fork length
|
1520mm
|
1520mm
|
1520mm
|
|
Machine weight
|
6500kg
|
10500kg
|
12000kg
|
|
Machine size
|
4600*2200*2850mm
|
5800*2200*3100mm
|
5800*2400*3300mm
|
Features
1.Thickened mast, strong bearing capacity
2.Hydraulic power steering wheel, easy to operate
3.cast steel axle,wheel reduction
4.Electrophoretic spray paint,the paint surface is smooth and not easy to rust
5.LED light,Hydraulic power steering wheel, easy to drive
6.Optional pneumatic tires/solid tires
