Quick Details
-
Max. Loading Capacity:
-
1000L
-
Weight (KG):
-
700 KG
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Topsail
-
Voltage:
-
220/380V, or customized
-
Dimension(L*W*H):
-
customized
-
Power (kW):
-
4 kW
-
Marketing Type:
-
New Product 2023
-
Stirrer type:
-
two directions frame-wall mixing
-
Control:
-
PLC or button
-
Heating method:
-
Electrical/steam heating
-
After-sales Service Provided:
-
Video technical support
-
After Warranty Service:
-
Online support
-
Local Service Location:
-
None
-
Certification:
-
CE/ISO
-
Homogenizing speed:
-
0-3000 r/min
Quick Details
-
Barrel Volume (L):
-
1350
-
Max. Loading Volume (L):
-
1000 L
-
Range of Spindle Speed(r.p.m):
-
1 - 63 r.p.m
-
Max. Loading Capacity:
-
1000L
-
Weight (KG):
-
700 KG
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Topsail
-
Voltage:
-
220/380V, or customized
-
Dimension(L*W*H):
-
customized
-
Power (kW):
-
4 kW
-
Marketing Type:
-
New Product 2023
-
Stirrer type:
-
two directions frame-wall mixing
-
Control:
-
PLC or button
-
Heating method:
-
Electrical/steam heating
-
After-sales Service Provided:
-
Video technical support
-
After Warranty Service:
-
Online support
-
Local Service Location:
-
None
-
Certification:
-
CE/ISO
-
Homogenizing speed:
-
0-3000 r/min
Products Description
Features:
1.Humanized overall layout of water-proof platform , convenient operation and nice appearance.
2.All types of emulsifying systems are easy to remove and maintain.
3.All types of emulsifying systems can be customized by the requirements of customers,with even division, safe and reliable mechanical seal;
4.HMM automatic operating system, transparent,various and brand-new controlled components;
5.The product production can save more energy and production time,which can completely improved production efficiency;
6.Can be coordinated the CIP/SIP system to reduce the water, electricity and other energy consumption;
7.This kind of product has wide usage, which can be used for the production and processing of all kinds of products.
Material Sources Of Parts:
80% of the main parts of our products are provided by world’s famous suppliers. During long-term cooperation and exchange with them, we have accumulated much valuable experience, so that we can provide customers with high quality products and more effective
guarantee.
Specification
|
Type
|
Homogenizer
|
|
Agitator
|
|
Vacuum pump
|
|
Heating power
|
|
||||
|
|
（KW）
|
（r/min）
|
（KW）
|
（r/min）
|
（KW）
|
Limit
vacuum
|
Electrical heating
|
Steam
heating
|
||||
|
PVM- 200L
|
4
|
0-3600
|
3
|
0-63
|
2.2
|
-0.09
|
40
|
14
|
||||
|
PVM- 300L
|
7.5
|
0-3600
|
4
|
0-63
|
2.2
|
-0.09
|
42
|
16
|
||||
|
PVM- 500L
|
11
|
0-3600
|
4
|
0-63
|
3.85
|
-0.09
|
55
|
18
|
||||
|
PVM- 1T
|
15
|
0-3600
|
7.5
|
0-63
|
5.5
|
-0.09
|
60
|
28
|
||||
|
PVM- 2T
|
18.5
|
0-3600
|
11
|
0-63
|
7.5
|
-0.09
|
/
|
42
|
||||
|
PVM- 3T
|
22
|
0-3600
|
15
|
0-63
|
7.5
|
-0.09
|
/
|
50
|
||||
|
PVM- 5T
|
22
|
0-3600
|
18.5
|
0-63
|
11
|
-0.09
|
/
|
66
|
||||
|
PVM- 10T
|
30
|
0-3600
|
22
|
0-63
|
15
|
-0.09
|
/
|
/
|
||||
Application
