Quick Details
-
Application:
-
Outdoor
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
XIANFENG
-
Model Number:
-
swing door operator ZK60
-
Type:
-
Automatic Door Operators
-
Power supply:
-
AC 220V/50Hz
-
Width of door section:
-
1.5m*2
-
Output torque:
-
100N.m
-
Certificate:
-
CE ISO
Quick Details
-
Warranty:
-
1 Year
-
After-sale Service:
-
Online technical support, Onsite Installation, Onsite Training, Onsite Inspection, Free spare parts, Return and Replacement
-
Project Solution Capability:
-
graphic design, 3D model design, total solution for projects, Cross Categories Consolidation
-
Application:
-
Outdoor
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
XIANFENG
-
Model Number:
-
swing door operator ZK60
-
Type:
-
Automatic Door Operators
-
Power supply:
-
AC 220V/50Hz
-
Width of door section:
-
1.5m*2
-
Output torque:
-
100N.m
-
Certificate:
-
CE ISO
ZK60 swing gate operator
Main features
This gate operator is used to drive folding gates which comprise two rectangular segments connected for articulation by hinges.
Three buttons (open, close, stop) on the control unit control the door separately.
The control system is fitted with wiring terminals for photocells and pressure sensor etc ..
Auto-reverse in the event of obstruction.
Manual operation in case of power failure.
Double limit switches to ensure the operator safety and reliability.
Technical specification :
|
Type |
ZK60 |
|
Power supply |
AC220 ×(1±10%)V 50Hz |
|
Motor speed |
960 rpm |
|
Output speed |
4 rpm |
|
Output torque |
30 N·m |
|
Output shaft aperture |
Φ25.4 mm |
|
Ambient temperature |
-20 º C ~ +50 º C |
|
Weight |
12 kg |
|
Dimension |
405*232*100 |
|
Thermal protection |
120 º C |
|
Continuous working time |
10 min |
Packaging: Neutral carton
Delivery Detail: Delivery time within 15-25working days
Shipping: Send by express, sea or air
1. Small MOQ is required, One set is available for checking our quality first conveniently
2. OEM/ODM is available, we can help to print logo on products.
3. Most advanced machines imported from German and make our products of high precision
4. All kinds of gate operators and road barriers, Widely product range can provide full solution to save your time and cost
5. Strong customization capability, we are very capable to custom produce with your drawings
6. The first manufacture of gate openers in China , We specialize in Automatic gate openers & gate automation for more than 27 years.
7. Fast & Cheap Delivery: We have big discount from forwarder (Long Contract).
8. Rich experience in selling and installing, also problem solving.
