Quick Details
-
Dimension (L*W*H):
-
442*440*145mm
-
Weight:
-
38kg
-
Protection Class:
-
IP20
-
Remote inteligent management:
-
Suppart 4G communication
-
Cloud platform management:
-
Support intelligent cloud platform/APP
-
DC charging part:
-
Wall-through fence terminal
-
Application:
-
Home Appliances, Electric Power Systems, Solar Energy
-
safety certificate:
-
CE,RCE,UN383,IEC62619
-
designed life:
-
10 years
-
Cycle life:
-
>6000 times
-
Warranty:
-
3-5 Years
-
OEM/ODM:
-
Support
-
MOQ:
-
1
Quick Details
-
Model Number:
-
RM51V100AH
-
Brand Name:
-
LeapPower
-
Place of Origin:
-
Guangdong, China
-
Dimension (L*W*H):
-
442*440*145mm
-
Weight:
-
38kg
-
Protection Class:
-
IP20
-
Remote inteligent management:
-
Suppart 4G communication
-
Cloud platform management:
-
Support intelligent cloud platform/APP
-
DC charging part:
-
Wall-through fence terminal
-
Application:
-
Home Appliances, Electric Power Systems, Solar Energy
-
safety certificate:
-
CE,RCE,UN383,IEC62619
-
designed life:
-
10 years
-
Cycle life:
-
>6000 times
-
Warranty:
-
3-5 Years
-
OEM/ODM:
-
Support
-
MOQ:
-
1
Products Description
Product Paramenters
|
Rated capacity
|
100Ah
|
200Ah
|
100Ah
|
200Ah
|
||||
|
Cycle
|
>6000 cycles
|
|
|
|
||||
|
Ydtage range
|
DC21.8-28.8V
|
DC21.6-28.8V
|
DC40.5-54V
|
DC40.5-54V
|
||||
|
BMS communication
|
RS485,RS232, CAN, Ethernet
|
|
|
|
||||
|
Bectrical parameter
|
|
|
|
|
||||
|
Rated enengy
|
2400wh
|
4800wh
|
4800wh
|
9600wh
|
||||
|
Minimum discharge voltage
|
20.8V
|
20.8V
|
39V
|
39V
|
||||
|
Max continuous charging cument
|
100A
|
200A
|
100A
|
200A
|
||||
|
Max continuous discharging
|
100A
|
200A
|
100A
|
200A
|
||||
|
currentMaximum charging voltage
|
28.8V
|
28.8V
|
54V
|
54V
|
||||
|
Installation mode
|
Hloor style
|
|
|
|
||||
|
Product parameters
|
|
|
|
|
||||
|
Dimension(LxDxH)
|
442×440×145mm
|
560×440×170mm
|
482×451×266mm
|
530×442x221mm
|
||||
|
Package size(L×DxH)
|
648×535×245mm
|
630-535×245mm
|
630×535×245mm
|
710×535×260mm
|
||||
|
Net weight
|
38kg
|
48kg
|
40kg
|
80kg
|
||||
|
Gross weigh
|
40kg
|
50kg
|
42kg
|
85kg
|
||||
|
IP grade
|
IP20
|
|
|
|
||||
|
Operating temperature range
|
Charging: 0-45℃ Discharging:-30-55℃
|
|
|
|
||||
|
Cooling mode
|
natural cooling
|
|
|
|
||||
|
Operating Humidity Range
|
0-95%(no condensation)
|
|
|
|
||||
|
Max working allitude
|
4000m (>3000mNeed to derate)
|
|
|
|
||||
|
display screen
|
Optional
|
|
|
|
||||
About Us
LeapPower
is a high-tech manufacturing enterprise in Guangdong Province focusing on the research and development, production and sales of home solar energy storage batteries. We are committed to providing the best cost-effective brand energy storage batteries for all countries and regions in the world, as well as creating the world's first-class and most trustworthy household energy storage brand.
LeapPower,
as a specialized technology driven and factory brand company, has obvious differences in its strength and scale and technology investment compared with similar products in the market. We have 50,000 square meters, fully equipped IS09001 factory, innovation research and development investment of 11.5%, with 4 production bases and 4 R & D centers evenly distributed in Dongguan, Shenzhen and other places. We are
the only
white list of EV lithium Battery recycling approved by the Chinese government in Dongguan.
