- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
YOYA
-
Model Number:
-
YY0062
-
Product Name:
-
Meter Socket Box
-
Material:
-
Aluminum Alloy
-
Rated Voltage:
-
120/240V
-
Protection Level:
-
IP55 IP65
-
Brand:
-
YOYA
-
Application:
-
Electric Power Transmission
-
Warranty:
-
3 Years
-
Certificate:
-
ISO9001
-
Sample Time:
-
7-15 Days
Quick Details
-
Voltage:
-
120V/240V
-
Current:
-
100A, 100A
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
YOYA
-
Model Number:
-
YY0062
-
Product Name:
-
Meter Socket Box
-
Material:
-
Aluminum Alloy
-
Rated Voltage:
-
120/240V
-
Protection Level:
-
IP55 IP65
-
Brand:
-
YOYA
-
Application:
-
Electric Power Transmission
-
Warranty:
-
3 Years
-
Certificate:
-
ISO9001
-
Sample Time:
-
7-15 Days
Recommend Products
Production Description
Meter Base Socket 100A Single Phase
Description
The round meter base socket 100A single phase is made of die cast aluminum.The electro-statically applied epoxy and polyester resins,which are baked on,from a durable,light gray exterior.The current carrying parts are mad of copper alloy.The ground connector is designed to insure a positive electrical connectio nby effectively clamping the conductor against a serrated surface.
1.Round meter socket 100Amps,120/240V AC,Single phase,4 terminals,2 or 3 wire Copper Jaw,Copper or aluminum connector.
2.The Die-cast Aluminum round meter socket,Gray color exterior.
3.The current carrying parts made of phosphor copper.
4.The ground connector is designed to in sure a positive electrical connection.
5.Stainless steel sealing ring.
6.Fix hub size:1/2,3/4,1,1-1/4 for option.
Application
1.Temporary service.
2.Outdoor advertising.
3.Small customer service.
4.Other low amperage requirements.
The round meter base socket 100A single phase is made of die cast aluminum.The electro-statically applied epoxy and polyester resins,which are baked on,from a durable,light gray exterior.The current carrying parts are mad of copper alloy.The ground connector is designed to insure a positive electrical connectio nby effectively clamping the conductor against a serrated surface.
1.Round meter socket 100Amps,120/240V AC,Single phase,4 terminals,2 or 3 wire Copper Jaw,Copper or aluminum connector.
2.The Die-cast Aluminum round meter socket,Gray color exterior.
3.The current carrying parts made of phosphor copper.
4.The ground connector is designed to in sure a positive electrical connection.
5.Stainless steel sealing ring.
6.Fix hub size:1/2,3/4,1,1-1/4 for option.
Application
1.Temporary service.
2.Outdoor advertising.
3.Small customer service.
4.Other low amperage requirements.
|
Product Name
|
Cat No.
|
Related Voltage
|
Gang
|
Fixed Hubs Size
|
|
Square Meter Socket
|
YY0062
|
100A，120／240V，4jaw
|
Single Phase
|
1/2", 3/4", 1", 1-1/4".
|
|
Round Meter Socket
|
OS-100
|
100A，120／240V，4jaw
|
Single Phase
|
1/2"
|
