Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
CQFF
-
Model Number:
-
DGM8500
-
Dimensions:
-
127.7*61.6*44mm
-
Frequency Range:
-
136-147Mhz(MHz),403-407/450-527Mhz(MHz)
-
Product Name:
-
handled walkie talkie
-
Audio Jack:
-
Outdoor
-
CTCSS:
-
121
-
Working Voltage:
-
3.6V
-
Antenna impedance:
-
50Ω
-
Battery Type:
-
3xAANiMH Rechargeable Battery
Quick Details
-
Talk Range:
-
25km
-
Terminal style:
-
Handheld
-
Storage Channel:
-
16
-
Place of Origin:
-
China
-
Brand Name:
-
CQFF
-
Model Number:
-
DGM8500
-
Dimensions:
-
127.7*61.6*44mm
-
Frequency Range:
-
136-147Mhz(MHz),403-407/450-527Mhz(MHz)
-
Product Name:
-
handled walkie talkie
-
Audio Jack:
-
Outdoor
-
CTCSS:
-
121
-
Working Voltage:
-
3.6V
-
Antenna impedance:
-
50Ω
-
Battery Type:
-
3xAANiMH Rechargeable Battery
Specification
Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine
PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
|
Transmitter
|
|
|
|
Transmit power
|
≤ 5W
|
|
|
Digital modulation method
|
4FSK
|
|
|
Modulation Limit (Analog 12.5kHz)
|
2.5kHz
|
|
|
FM noise (analog 12.5kHz)
|
-40dB
|
|
|
Emission spurs
|
-36dB (≤ 1GHz), -30dB (>1GHz)
|
|
|
Adjacent channel power 12.5kHz
|
-60dB
|
|
|
Modulation Characteristics (Analog)
|
+1dB and -3dB
|
|
|
Digital transmit bit error rate
|
≤5%
|
|
|
Radio type (digital modulation)
|
7K60FXD and 7K60FXE
|
|
|
Receiver
|
|
|
|
Digital Receive Sensitivity: (5% BER)
|
0.2μV
|
|
|
Frequency Stability
|
±2.5ppm
|
|
|
Adjacent channel selectivity 12.5kHz
|
60dB
|
|
|
Intermodulation
|
55dB
|
|
|
Spurious Response Suppression
|
70dB
|
|
|
Co-channel rejection 12.5kHz
|
12dB
|
|
|
Conducted Spurious Radiation
|
-57dBm (<1GHz); -47dBm (>1GHz)
|
|
|
Blocking
|
84dB
|
|
|
Rated audio power
|
1W/16Ω (internal speaker); 500mW/8Ω (external speaker)
|
|
