Quick Details
-
Model Number:
-
350W 380W 400W 450W 460W 500W 550W 600W 650W
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
182mmx182mm
-
Power:
-
550W
-
Application:
-
Solar Power System
-
Junction Box:
-
IP65 Rated
-
Package Type:
-
Standard export carton + pallet
-
Selling Units:
-
Single item
-
Open-circuit Voltage:
-
49.62V
-
Working Current:
-
13.45A
-
Product name:
-
Sola Panel
-
Solar cell:
-
A-grade
-
Certificate:
-
CE,TUV,TUV;CE;ISO
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell, Bifacial, Customized Solar Panel
-
Panel Efficiency:
-
21.79%
-
Model Number:
-
350W 380W 400W 450W 460W 500W 550W 600W 650W
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
182mmx182mm
-
Power:
-
550W
-
Application:
-
Solar Power System
-
Junction Box:
-
IP65 Rated
-
Package Type:
-
Standard export carton + pallet
-
Selling Units:
-
Single item
-
Open-circuit Voltage:
-
49.62V
-
Working Current:
-
13.45A
-
Product name:
-
Sola Panel
-
Solar cell:
-
A-grade
-
Certificate:
-
CE,TUV,TUV;CE;ISO
Specification
|
Maximum Power (Pmax)
|
450W
|
480W
|
500W
|
550W
|
600W
|
|
Open Circuit Voltage (Voc)
|
49.64V
|
49.78V
|
49.95V
|
50.18V
|
50.32V
|
|
Short Circuit Current (Isc)
|
13.62A
|
13.67A
|
13.76A
|
14.05A
|
14,12A
|
|
Voltage at Maximum power (Vmpp)
|
40.21V
|
40.57V
|
41.75V
|
42.15V
|
43.51V
|
|
Current Maximum Power (Impp)
|
11.19A
|
11.83A
|
11.98A
|
13.05
|
13.78A
|
|
No. of Cells
|
144 (6x24)
|
144 (6x24)
|
144 (6x24)
|
144 (6x24)
|
144 (6x24)
|
|
Connectors
|
Mc4
|
Mc4
|
Mc4
|
Mc4
|
Mc4
|
|
Mechanical load test
|
5400Pa
|
5400Pa
|
5400Pa
|
5400Pa
|
5400Pa
|
|
MODULE EFFICIENCY (%)
|
21.51%
|
21.51%
|
21.51%
|
21.51%
|
21.51%
|
|
Operating Module Temperature
|
-40°Cto + 85°C
|
-40°Cto + 85°C
|
-40°Cto + 85°C
|
-40°Cto + 85°C
|
-40°Cto + 85°C
|
|
Maximun System Voltage
|
1500 DC (IEC)
|
1500 DC (IEC)
|
1500 DC(IEC)
|
1500 DC(IEC)
|
1500 DC (IEC)
|
|
Maximun Series Fuse Rating
|
25A
|
25A
|
25A
|
25A
|
25A
|
|
Power Tolerance
|
0/+5W
|
0/+5W
|
0/+5W
|
0/+5W
|
0/+5W
|
|
Nominal Operating Temperature (Noct)
|
45±2°C
|
45±2°C
|
45±2°C
|
45±2°C
|
45±2°C
|
|
Temperature Coefficient of Pmax
|
-0.36%°C
|
-0.36%°C
|
-0.36%°C
|
-0.36%°C
|
-0.36%°C
|
|
Temperature Coefficient of Voc
|
-0.28%°C
|
-0.28%°C
|
-0.28%°C
|
-0.28%°C
|
-0.28%°C
|
|
Temperature Coefficient of Isc
|
+0.05%°C
|
+0.05%°C
|
+0.05%°C
|
+0.05%°C
|
+0.05%°C
|
