Quick Details
-
Filling Accuracy:
-
±0.5%
-
Voltage:
-
110V220V/380V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SHAOFENG
-
Dimension(L*W*H):
-
Customizable
-
Weight:
-
150 KG
-
After-sales Service Provided:
-
Online Support
-
Function:
-
Liquid Filling Weighing
-
Suitable for:
-
Liquid
-
Filling speed:
-
20-40 BPH
-
Filling volume:
-
5-300KG
-
Material:
-
SUS304
-
Operation:
-
Button Control
-
Filling nozzles:
-
1, 2
-
Drum type:
-
Plastic/Iron/SUS
Quick Details
-
Machinery Capacity:
-
20-40BPH
-
Packaging Material:
-
Plastic, Metal, Other
-
Filling Material:
-
Milk, Water, Oil, Juice, Lubricant, Palm, Paint
-
Filling Accuracy:
-
±0.5%
-
Voltage:
-
110V220V/380V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SHAOFENG
-
Dimension(L*W*H):
-
Customizable
-
Weight:
-
150 KG
-
After-sales Service Provided:
-
Online Support
-
Function:
-
Liquid Filling Weighing
-
Suitable for:
-
Liquid
-
Filling speed:
-
20-40 BPH
-
Filling volume:
-
5-300KG
-
Material:
-
SUS304
-
Operation:
-
Button Control
-
Filling nozzles:
-
1, 2
-
Drum type:
-
Plastic/Iron/SUS
Product Description
Specification
|
Filling Range
|
Max 300 kg
|
|
|
Display Division Value
|
100g
|
|
|
Filling Precision
|
±0.1% F.S.
|
|
|
Filling Speed
|
25-50 BPH
|
|
|
Voltage
|
220 V 50 hz 1 phase
|
|
|
Air Supply
|
0.6Mpa
|
|
|
Operating Temperature
|
-10ºC-50ºC;
|
|
|
Relative Humidity
|
< 95% (no condensation);
|
|
|
Control Method
|
Two-section liquid infeed weight control (with backflow control)
|
|
|
Filling Method
|
Submersible type
|
|
|
Weighing Platform Size
|
700 * 700 mm*250 mm
|
|
|
Spray Gun Head Tube
|
Teflon;
|
|
|
Tube Pressure
|
0.2-0.6MPa
|
|
|
Material Interface
|
DN50-flange joint;
|
|
|
Air Source Interface
|
The user provides G1/2 internal thread for quick connector connection;
|
|
|
This machine is customizable according to your requirements.
|
|
|
Applications
Packing & Delivery
Normally, Wooden Case Or Packaging Film, Also Can Be Customized.
