Quick Details
-
Ice storage capacity:
-
customized
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CBFI
-
Dimension(L*W*H):
-
customized
-
Weight:
-
1000 KG
-
Warranty:
-
15 Months
-
Application:
-
Industrial or Commercial
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Keywords:
-
ice making machines 5t/24hrs
-
Refrigerant:
-
R22/R404a
-
Electrical components:
-
Korea LG
-
Expansion valve:
-
Danmark - Danfoss Brand
-
Solenoid valve:
-
Italy Castel
-
Cooling way:
-
Water Cooling/Air Cooling Tube ice machine
-
Control system:
-
PLC
-
Evaporator inner material:
-
stainless steel 304
-
Tube ice diameter:
-
30-50mm Tube ice machine
Quick Details
-
Ice Shape:
-
Granular Ice
-
Voltage:
-
380v/220V
-
Power:
-
26.95kw
-
Ice storage capacity:
-
customized
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CBFI
-
Dimension(L*W*H):
-
customized
-
Weight:
-
1000 KG
-
Warranty:
-
15 Months
-
Application:
-
Industrial or Commercial
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Keywords:
-
ice making machines 5t/24hrs
-
Refrigerant:
-
R22/R404a
-
Electrical components:
-
Korea LG
-
Expansion valve:
-
Danmark - Danfoss Brand
-
Solenoid valve:
-
Italy Castel
-
Cooling way:
-
Water Cooling/Air Cooling Tube ice machine
-
Control system:
-
PLC
-
Evaporator inner material:
-
stainless steel 304
-
Tube ice diameter:
-
30-50mm Tube ice machine
Product Description
Product Details
Product Parameters
|
3 tons per day large capacity cube ice machine for hotels & restaurants paremeters
|
|
|
|
|
|
|
|
|||||||
|
Model Parameters
|
|
CV 1000
|
CV 2000
|
CV 3000
|
CV 5000
|
CV 10000
|
CV 20000
|
|||||||
|
Daily output (T/24 h)
|
|
1
|
2
|
3
|
5
|
10
|
20
|
|||||||
|
Compressor Power
|
|
4.34 kw
|
7.88 kw
|
10.58 kw
|
21 kw
|
42 kw
|
73.5 kw
|
|||||||
|
Fan Power of Cooling Tower
|
|
0.18 kw
|
0.37 kw
|
0.56 kw
|
0.75 kw
|
1.5 kw
|
2.2 kw
|
|||||||
|
Cooling Pump Power
|
|
1.1 kw
|
1.5 kw
|
1.5 kw
|
2.2 kw
|
4 kw
|
5.5 kw
|
|||||||
|
|
L (mm)
|
1800
|
1630
|
1980
|
2890
|
5730
|
7100
|
|||||||
|
|
W (mm)
|
1000
|
1600
|
1630
|
1780
|
1780
|
2250
|
|||||||
|
|
H (mm)
|
1700
|
1706
|
1860
|
1860
|
2130
|
2300
|
|||||||
|
Unit N.W. (kg)
|
|
800
|
1000
|
1200
|
1600
|
3000
|
5000
|
|||||||
|
1. Size of cube ice: 22*22*22 mm ; 29*29*22 mm ; 38*38*22 mm.
2. Compressor brand: Bizter / Frascold; refrigerant: R22/ R404A;Cooling Method: Water Cooling / Air Cooling.
3. Power Supply: Voltage 380V/3P/50Hz (For non-standard voltage, unit configuration needs to be calculated separately). 4. Operating Conditions: T(water supply):20 ℃, T(ambient):32 ℃, T(condensing): 40 ℃, T(evaporating):-10 ℃. 5. Note: The actual ice production varies due to the influence of the water supply temperature and ambient temperature. 6. The final interpretation of the above mentioned parameter is in Icesource, there will be further notice, if there any technical change. |
|
|
|
|
|
|
|
|||||||
Successful Project
Packing process
Ice maker machine
1. Standard wooden case.
2. Completely ice machine contain: ice machine, cooling tower, water pump, water pipes and water pipe fittings.
3. Machine come into use, customer only need prepare power for the machine. 4. All required components for install the machine will be provide.
Contact us
About us
FAQ
1.Q：Are you add refrigerant in the ice machine?
A:Yes, our equipment is filled with refrigerant, and it can be used as long as it is connected to electricity and water.
2.Q：Do you test the ice machine in your factory?
A: Yes, Our equipment will be tested twice before being put into use: factory inspection and operation test after installation at the buyer's destination to ensure that we provide the best service to customers.In addition, our company can provide a complete set of solutions for the actual needs of customers. Creating value and fulfilling customers is our principle.
3.Q: All your ice machine is based on 380V 50HZ power requirement? Do you have the right power requirement for aboard? Such as 440V 60HZ or 220V three phase that suitable for America?
A: Our ice machine and power, voltage can suitable for your country, please make the power requirement be clear in your order.
4.Q: Whats the deliver time of your machine?
A:1~5ton, 30 days since the deposit arrived at our account, 5~20 ton, 45 days. (based on the electricity 380V/50Hz/3p, some special design lead time will be longer )
A:Yes, our equipment is filled with refrigerant, and it can be used as long as it is connected to electricity and water.
2.Q：Do you test the ice machine in your factory?
A: Yes, Our equipment will be tested twice before being put into use: factory inspection and operation test after installation at the buyer's destination to ensure that we provide the best service to customers.In addition, our company can provide a complete set of solutions for the actual needs of customers. Creating value and fulfilling customers is our principle.
3.Q: All your ice machine is based on 380V 50HZ power requirement? Do you have the right power requirement for aboard? Such as 440V 60HZ or 220V three phase that suitable for America?
A: Our ice machine and power, voltage can suitable for your country, please make the power requirement be clear in your order.
4.Q: Whats the deliver time of your machine?
A:1~5ton, 30 days since the deposit arrived at our account, 5~20 ton, 45 days. (based on the electricity 380V/50Hz/3p, some special design lead time will be longer )
