1;Have an automatic fire extinguishing device,intelligent BMS
2;Aviation quick connection line, scientific cooling air duct
3;Can compatible multiple solar inverter devices
4;Intelligent parallel control circuit, adaptive parallel voltage balance
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
CUNVAE
-
Model Number:
-
24100
-
Battery Size:
-
24100, 24V100Ah
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
38KG, 38Kg±0.5
-
The charging ratio:
-
0.5C, 0.2c
-
The discharge rate:
-
0.5C
-
Capacity:
-
100ah
-
Battery Model:
-
24V/3200wh
-
Size:
-
471*150*375mm
-
Energy:
-
2.4kw
-
Discharge current:
-
1c
-
Nominal voltage:
-
24v
-
Certification:
-
CE ROHS MSDS UN38.3 ISO9001
-
Warranty:
-
3YEAR
Quick Details
-
Storage Type:
-
dry, cool and ventilation
-
Anode Material:
-
LFP
-
Application:
-
Home Appliances, BOATS, Golf Carts, Electric Bicycles/Scooters, Electric Folklifts, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies, Electric Forklifts
-
Brand Name:
-
CUNVAE
-
Model Number:
-
24100
-
Battery Size:
-
24100, 24V100Ah
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
38KG, 38Kg±0.5
-
The charging ratio:
-
0.5C, 0.2c
-
The discharge rate:
-
0.5C
-
Capacity:
-
100ah
-
Battery Model:
-
24V/3200wh
-
Size:
-
471*150*375mm
-
Energy:
-
2.4kw
-
Discharge current:
-
1c
-
Nominal voltage:
-
24v
-
Certification:
-
CE ROHS MSDS UN38.3 ISO9001
-
Warranty:
-
3YEAR
About SenWei
*
16Year Battery Manufacturer
* Do Retails,Wholesales,Dropshipping,Distributions
* OEM , ODM ,NO MOQ(No Minimium Qantities),Zero Risk,Quality Assurance
* Dispatch to Worldwide,by sea,by air,by express,by postoffice registeral mail,Overseas warehouse service,Fast Shipping
* Do Retails,Wholesales,Dropshipping,Distributions
* OEM , ODM ,NO MOQ(No Minimium Qantities),Zero Risk,Quality Assurance
* Dispatch to Worldwide,by sea,by air,by express,by postoffice registeral mail,Overseas warehouse service,Fast Shipping
Product Description
Features
1.Advanced BMS with current limiting function;
1.Advanced BMS with current limiting function;
2.Long cycle life and service life;
3.Compatible with most inverters and chargers;
4.Low self discharge;
5.High energy intensity and conversion efficiency;
6.Easy rack-mounted installation;
7.Solid handles in front for carrying and moving;
8.Excellent high temperature performance;
9.Overcharge,over discharge and over temperature protection;
10.More compact volume and lighter weight;
11.Customization accepted;
3.Compatible with most inverters and chargers;
4.Low self discharge;
5.High energy intensity and conversion efficiency;
6.Easy rack-mounted installation;
7.Solid handles in front for carrying and moving;
8.Excellent high temperature performance;
9.Overcharge,over discharge and over temperature protection;
10.More compact volume and lighter weight;
11.Customization accepted;
Specification
|
Basic Parameters
|
Voltage
|
24V 100AH
|
|
|
|
|||
|
|
Capacity
|
100Ah(Standard )
|
|
|
|
|||
|
|
Energy
|
100Ah, 2560Wh @C2, 25℃
|
|
|
|
|||
|
|
Operating Voltage Range
|
20V DC-28.8V DC
|
|
|
|
|||
|
|
Cycle Life @ 80% DOD
|
＞4000 Cycles(80% DOD @C2, 25℃)
|
|
|
|
|||
|
|
Self discharge
|
<5%(after 90 days storage)
|
|
|
|
|||
|
|
Standard warranty
|
3 years(longer warranty according to customers)
|
|
|
|
|||
|
Size and weight
|
Size
|
442*440*145(mm)
|
|
|
|
|||
|
|
Weight
|
≤38Kg
|
|
|
|
|||
|
Electrical Parameters
|
Charging mode
|
constant current
|
|
|
|
|||
|
|
Charging Current
|
0.5C(Standard)
|
|
|
|
|||
|
|
|
1C(Maximum constant current@25℃)
|
|
|
|
|||
|
|
Overcharge protection voltage
|
29.4V
|
|
|
|
|||
|
|
Discharge mode
|
constant current
|
|
|
|
|||
|
|
Over-discharge protection voltage
|
20.3V
|
|
|
|
|||
|
Working Parameters
|
Working Temperature
|
Charging (Small Current):-10℃~+55℃
|
|
|
|
|||
|
|
|
Discharge(Small Current)-20℃~+55℃
|
|
|
|
|||
|
|
Storage Temperature
|
Conventional storage temperature:-10~+45℃(Three months ,SOC:20%~60%)
|
|
|
|
|||
|
|
|
Conventional storage temperature:-10~+45℃(Three months ,SOC:20%~60%)
|
|
|
|
|||
|
|
Storage Humidity
|
5%~95%
|
|
|
|
|||
|
|
Transportation Environment
|
Voltage:3.25V~3.35V
|
|
|
|
|||
|
|
|
SOC:30%~60%
|
|
|
|
|||
