Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
WEIER
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
18*1.5*2.6 m
-
Power (kW):
-
11
-
Weight:
-
8.5
-
Type:
-
PE single wall corrugated pipe production line
-
Raw material:
-
PE
Quick Details
-
Screw Design:
-
Single-screw
-
Screw L/D Ratio:
-
30:1
-
Screw Speed (rpm):
-
1440 rpm
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
WEIER
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
18*1.5*2.6 m
-
Power (kW):
-
11
-
Weight:
-
8.5
-
Type:
-
PE single wall corrugated pipe production line
-
Raw material:
-
PE
|
SJ-45/30 single-screw plastic extruder |
|||
|
Screw |
Material of screw |
38CrMoAlA, by nitriding treatment, |
|
|
Hardness |
HV950-1050 |
||
|
Nitriding depth |
0.4~0.7mm |
||
|
Screw diameter |
45mm |
||
|
length to diameter |
30:1 |
||
|
barrel |
heating zones |
3 zones |
|
|
hardness |
HV950 - 1050 |
||
|
material |
38CrMoAIA,by nitriding treatment |
||
|
nitriding layer |
0.4 - 0.7mm |
||
|
heater |
cast aluminum heater |
||
|
resistive heating |
|||
|
cooling |
model |
wind cooling |
|
|
power |
60Wx3 |
||
|
decelerator |
material of tank body |
HT200 |
|
|
material of gear |
20CrMnTi |
||
|
hardness treatment of gear surface |
Nitride, quenching, gear-grinding |
||
|
precision of gear |
GB10095 - 88.6grade |
||
|
motor |
model |
frequency speed-controlling |
|
|
power |
11kw (AC motor) |
||
|
speed |
1440r/min |
||
|
temperature-controlling |
model |
LCD display, PID control |
|
|
controlling scope |
0 - 399 ℃ |
||
|
feeding equipment |
automatic material-lifting and drying system |
||
1. Product electrical components to implement quality assurance for six months (from date of shipment)
2. Equipment Quality Assurance warranty period of one year (from date of shipment)
3. Quality guarantee period, should the damage appears artificial parts, the company will be provided free of charge to the purchaser Manufacturers
4. Quality guarantee period, the company will provide the most preferential prices paid to the purchaser Manufacturers
5. "Supply-side free of charge to provide the main electrical appliances, spare parts manual and maintenance of books, equipment manuals, and machine maintenance information, provision of equipment, water, electricity, gas and equipment installation plans.
6. For the party responsible for assisting in installation, commissioning and training services, equipment, three bags of one year after leaving the factory, three bags of equipment, one year after the supply of spare parts according to price. "
