Quick Details
-
Size:
-
6325
-
tyre:
-
185R14C with alloy rims
-
horse bay:
-
adjustable and fully padded
-
rug rack:
-
lockable and fully length
-
roof:
-
fiberglass roof with roof lining
-
axles:
-
50*50mm
-
brakes:
-
4 wheels electrical brake
-
safety chain:
-
stamped
Quick Details
-
Max Payload:
-
2400kg
-
Brand Name:
-
Jinli
-
Place of Origin:
-
Shandong, China
-
Size:
-
6325
-
tyre:
-
185R14C with alloy rims
-
horse bay:
-
adjustable and fully padded
-
rug rack:
-
lockable and fully length
-
roof:
-
fiberglass roof with roof lining
-
axles:
-
50*50mm
-
brakes:
-
4 wheels electrical brake
-
safety chain:
-
stamped
horse floats australia standards 2hal living float
2HAL deluxe with living float fitted with:
bunk ned: sofa& table, which could converted to bed; with upper bed
fully kitchen cupboard, with clothes/tall cupboard, overhead cupboard, water system(water tank100L , pump, sink, internal & external tap)
shower/ water heater in the dividing wall
dividing wall with door from horse area to living area
caravan door
FIAMMA awning
Jinan Jinli Hydraulic Machinery Co.,Ltd is the biggest horse float manufacturer in China with 20000 square meter factory, 12 years excperience. we do manufacture standard float and customized float, gooseneck, dog trailer etc.
looking forward to long-term business partners
|
MODEL:2HAL- D |
|
1 .1 CHASSIS MATERIAL double hot dip galvanized RHS(3.5mm-4.0mm) |
|
1. 2 FRAME MATERIAL double hot dip galvanized RHS(2.5mm) |
|
1. 3 BODY PANEL galvanized (1.2mm) |
|
1. 4 ROOF special molded FRP 5300 *1980 |
|
1. 5 NUTS & BOLTS stainless steel |
|
2. 1 WHEEL RIM 4* 14' aluminium alloy rims |
|
2.2 TYRES 4* 185R14C |
|
2.3 SPARE WHEEL one |
|
5.1 DRAWBAR CHECKER PLATE 1.2mm aluminium |
|
5.2 DRAWBAR SAFETY CHAIN two |
|
5.3 BRACING WHEEL one |
|
6.LIGHTS & RETRO REFLECTORS |
|
6.1 TRAILER PLUGS square 7 wick plug |
|
6.2 SIDE LAMPS 6 |
|
6.3 REAR LAMPS LED group 6.4 REAR LAMPS STAND alumin i um |
|
6.5 RETRO REFLECTORS 6 |
|
7.1 MUDGUARD TYPE |
|
7.2 MUDGUARD CHECKER PLATE 1.2mm aluminium in the front of mudguard |
|
7.3 PEDAL & ALUMINIUM STEP 1.2mm aluminium decoration board |
|
8.INTERIOR & EXTERIOR |
|
8.1 LIVING ROOM s eating area with table that folds down to a bed big enough to sleep 2 people. |
|
8.2 BAY LENGTH AND BAY WIDTH 2400mm and 750 mm |
|
8. 3 HORSE PROTECTION FRAME full padded and dividers are removable |
|
8.4 LINED INNNER ROOF yes |
|
8.5 INNER LIGHTS two 12 volt LED lights in horse area and two in living room |
|
8.6 SHOWER one in horse area |
|
8. 7 FLUSH TIE UP RINGS four |
|
8. 8 RUBBER MATTING FOR RAMP DOOR 10mm rubber matting |
|
8. 9 RUBBER MATTING FOR FLOOR 10mm rubber matting |
|
8. 10 RUBBER MATTING FOR INNER SIDE PANEL 10 mm rubber matting |
|
8. 11 WOOD BOARD FOR FLOOR & RAMP DOOR 18mm hardwood plywood |
|
8. 12 RUG RACK side with gas-loaded doors |
|
8.1 4 SADDLE BOX 1200mm height for 2 saddles , swing out |
|
8.1 5 PAINTING Silver and Burgandy with patterns |
|
9.1 OVERALL DIMENSIONS ( L x W x H: mm ) 6325 *22 8 0*2590 |
|
9.2 BODY DIMENSIONS ( L x W x H: mm ) 5475 *1980*2230 |
|
9.3 INNER DIMENSIONS ( L x W x H: mm ) 5450 *1930*2155 |
detail photos
