Quick Details
-
Brand Name:
-
Lovsun
-
Model Number:
-
HW-30M
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
721x 500 x8 mm
-
Product name:
-
Hantile 30W BIPV Roof Tiles Solar Panel
-
Junction Box:
-
IP67
-
Weight:
-
Weight
-
Single product power:
-
25-32W
-
Power per level:
-
62-110W
-
Component thickness:
-
8mm
-
Fire rating:
-
A
-
Windproof grade:
-
F
-
Component weight per square meter:
-
22kg
-
Color:
-
zero carbon black, golden brick red, emerald green
Quick Details
-
Cell size:
-
125mmx125mm
-
Type:
-
BIPV
-
Warranty:
-
10 Years For Material And Processing
-
Brand Name:
-
Lovsun
-
Model Number:
-
HW-30M
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
721x 500 x8 mm
-
Product name:
-
Hantile 30W BIPV Roof Tiles Solar Panel
-
Junction Box:
-
IP67
-
Weight:
-
Weight
-
Single product power:
-
25-32W
-
Power per level:
-
62-110W
-
Component thickness:
-
8mm
-
Fire rating:
-
A
-
Windproof grade:
-
F
-
Component weight per square meter:
-
22kg
-
Color:
-
zero carbon black, golden brick red, emerald green
Product Description
Component weight:6.5(± 0.5)kg
Component weight per square meter: 22(± 0.5) kg
Single product power: 25-32W
Power per level:62-110W
Color:zero carbon black, golden brick red,emerald green
Linear power guarantee: 25 years
Load level:5400Pa(maximum static load on the front, including snow load and wind load)
Waterproof grade: IP67
Fire rating: A
Windproof grade: F
Hail resistance: maximum diameter 25mm, impact speed 23m/s
Operating temperature:-40~+85
Component weight per square meter: 22(± 0.5) kg
Single product power: 25-32W
Power per level:62-110W
Color:zero carbon black, golden brick red,emerald green
Linear power guarantee: 25 years
Load level:5400Pa(maximum static load on the front, including snow load and wind load)
Waterproof grade: IP67
Fire rating: A
Windproof grade: F
Hail resistance: maximum diameter 25mm, impact speed 23m/s
Operating temperature:-40~+85
|
TECHNICAL PARAMETER
|
|
|
|
Specification
|
721mm(length), 500mm(width)
|
|
|
Weight
|
6.5kg
|
|
|
Linear power guarantee
|
25 Year
|
|
|
Power
|
30W
|
|
|
Short-circuit current
|
4A
|
|
|
Load rating
|
5400Pa
|
|
|
Waterproof rate
|
IP67
|
|
|
Fire rating
|
A
|
|
|
Wind protection rating
|
F
|
|
|
Hail resistance rating
|
4 Class
|
|
|
Operating temperature
|
-40°C to +85°C
|
|
