Quick Details
-
Board Size:
-
Custom
-
Model Number:
-
Custom PCB/PCBA Assembly
-
Type:
-
Custom
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
LHD Technology
-
Copper Thickness:
-
0.5oz-14oz
-
Min. Hole Size:
-
0.1mm(HDI)/0.15mm via
-
Min. Line Width:
-
2.5mil(0.05mm)
-
Min. Line Spacing:
-
2.5mil(0.05mm)
-
Surface Finishing:
-
LFHASL/OSP/ENIG/ENEPIG/Gold finger
-
Product name:
-
PCB
-
Application Area:
-
Automotive, Medical, Industry, IOT, Smart Home, security equipment,
-
Capacity:
-
70 million placements per month
-
Max board size:
-
457 * 356(18'' * 14'')
-
Speed:
-
0.15sec/chip,0.7sec/QFR
-
Wave soldering:
-
2
-
Max board width:
-
400mm
-
Max Temper:
-
399 Degree C
-
Spray flux:
-
add-on
-
Quality Assurance:
-
AOI IQC PQC QA
Quick Details
-
Number of Layers:
-
2-32 layers
-
Base Material:
-
Fr4/Roger/Polyimide/Metal Base
-
Board Thickness:
-
0.1mm-7.0mm
-
Board Size:
-
Custom
-
Model Number:
-
Custom PCB/PCBA Assembly
-
Type:
-
Custom
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
LHD Technology
-
Copper Thickness:
-
0.5oz-14oz
-
Min. Hole Size:
-
0.1mm(HDI)/0.15mm via
-
Min. Line Width:
-
2.5mil(0.05mm)
-
Min. Line Spacing:
-
2.5mil(0.05mm)
-
Surface Finishing:
-
LFHASL/OSP/ENIG/ENEPIG/Gold finger
-
Product name:
-
PCB
-
Application Area:
-
Automotive, Medical, Industry, IOT, Smart Home, security equipment,
-
Capacity:
-
70 million placements per month
-
Max board size:
-
457 * 356(18'' * 14'')
-
Speed:
-
0.15sec/chip,0.7sec/QFR
-
Wave soldering:
-
2
-
Max board width:
-
400mm
-
Max Temper:
-
399 Degree C
-
Spray flux:
-
add-on
-
Quality Assurance:
-
AOI IQC PQC QA
Electronic Manufacturing Service Professional Pcb Multilayer Pcb Fr4
Specification of PCB Manufacturing
| Items | Paramerers |
| Double side/Mulyti-layer | |
| Max panel size | 32'*20'(800mm*508mm) |
| Minimum track/gap IL | 0.075mm/0.075mm(3mil/3mil) |
| Min annular ring on inner layer one side | 3mil(0.075mm) |
| Maximum Cu weight OL | 6oz(210um) |
| Maximum Cu weight 1L | 12oz(420um) |
| Finished board thickness | 0.20-6mm |
| Layer count | 2-32L |
| Layer to layer registration | ±3mil(±76um) |
| Min finished hole diameter | 0.15mm(6mil),0.1mm(4mil) for HDI |
| Hole position Accuracy | ±2mil(±50um) |
| Slot hloe Tolerance | ±3mil(±75um) |
| PTH diameter tolerance | ±2mil(±50um) |
| NPTH diameter tolerance | ±1mil(25±um) |
| Max Aspect ratio PTH | 10:1 |
| Copper on the wall of the holes | 0.4-2mil(10-50um) |
| Grapic pattern registration tolerance | ±3mil(0.075um) |
| Minimum track/gap 1L(mil)-copper weight dependant | 3mil/3mil(75um/75um) |
| The track Etching tolerance | ±1mil(±25um) |
1, What service could you provide ?
We could provide PCB design,PCBA design,PCB printing,PCB assembly,Components procurement,Reverse-Engineer.
2, What is needed for PCB & PCBA quotation?
For PCB: Quantity, Gerber file and technic
al
requirements(material,size, surface finish treatment, copper thickness,board thickness).
For PCBA: PCB information, BOM,Testing documents.
3, How to keep our product information and design file secret ?
We could sign NDA associate by customers side local law for protecting customers confidential business
4, What are the main products of your PCB/PCBA services?
Automotive, Medical, Industry Control, IOT, Smart Home, security equipment, Aerospace.
5, What is your minimum order quantity (MOQ)?
Our MOQ is 1 PCS, sample and mass production all can support.
6, Are you factory?
Our factory is located in No.26,Meiyuan 3rd Road,Intercontinental Industrial Park,Luoyang Town,Boluo County,Huizhou, Guangdong, China.
7.How can we guarantee you receive an good quality product?
For PCB, we will use Flying Probe Test, E-test etc. for it.
For PCBA, we need you to offer us a method or test fixture for the function test.Before that, our inspectors will use microscope and X-ray to check the IC footwelding or bad solder etc.
8.What payment terms do we accept?
For sample order or small batch, we suggest you to use Paypal and Western Union.For mass production batch, we suggest you to use T/T.
