Quick Details
-
Power:
-
4.5kw
-
Table Size:
-
2.26 * 1.13* 1.1m
-
Overall Dimensions:
-
2.475x1.15x2.414m
-
Weight:
-
2300 kg
-
Working Height Maxdmum:
-
12m
-
Platform Height Maximum:
-
10m
-
Safe working load:
-
230kg
-
Extended platlorm safe working load:
-
100kg
-
Length extension deck:
-
0.9m
-
Ground clearance-center:
-
0.1/0.02m
-
Wheelbase:
-
1.89m
-
Lifting / driving motor:
-
24V/4.5kw
-
Lifting speed:
-
3-5m/min
-
Battery:
-
4x6V/225Ah
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
China
-
Brand Name:
-
LTMG
-
Power:
-
4.5kw
-
Table Size:
-
2.26 * 1.13* 1.1m
-
Overall Dimensions:
-
2.475x1.15x2.414m
-
Weight:
-
2300 kg
-
Working Height Maxdmum:
-
12m
-
Platform Height Maximum:
-
10m
-
Safe working load:
-
230kg
-
Extended platlorm safe working load:
-
100kg
-
Length extension deck:
-
0.9m
-
Ground clearance-center:
-
0.1/0.02m
-
Wheelbase:
-
1.89m
-
Lifting / driving motor:
-
24V/4.5kw
-
Lifting speed:
-
3-5m/min
-
Battery:
-
4x6V/225Ah
|
Model
|
LTWP0810
|
LTWP1012
|
LTWP1214
|
|
Working Height Maxdmum
|
10.00m
|
12.00m
|
14.00m
|
|
Platform Height Maximum
|
8.00m
|
10.00m
|
12.00m
|
|
Safe working load
|
230kg
|
230kg
|
230kg
|
|
Extended platlorm safe working load
|
100kg
|
100kg
|
100kg
|
|
Working platform size (L*w*h)
|
2.26x0.81 x 1.1m
|
2.26x1.13x1.1m
|
2.26x1.13x1.1m
|
|
Overall size
|
2.475x0.81 x 2.286m
|
2.475x1.15x2.414m
|
2.475x1.15 x 2.542m
|
|
Overall size
|
2.475x0.81 x 1.836m
|
2.475 x1.15 x1.964m
|
2.475 x 1.15 x 2.094m
|
|
Length extension deck
|
0.9m
|
0.9m
|
0.9m
|
|
Ground clearance-center
|
0.1/0.02m
|
0.1/0.02m
|
0.1/0.02m
|
|
Wheelbase
|
1.89m
|
1.89m
|
1.89m
|
|
Turning radius (inner/ outer wheel)
|
0/2.1 m
|
012.2m
|
0/2.2m
|
|
Lifting / driving motor
|
24V/4.5kw
|
24V/4.5kw
|
24V/4.5kw
|
|
Lifting speed
|
3-5m/min
|
3-5m/min
|
3-5m/min
|
|
The machine speed (folded state)
|
3.5km/h
|
3.5km/h
|
3.5km/h
|
|
Machine travel speed (lifting state)
|
0.8km/h
|
0.8km/h
|
0.8km/h
|
|
Battery
|
4x6V/225ah
|
4x6V/225ah
|
4x6V/245ah
|
|
Charger
|
24V/25A
|
24V/25A
|
24V/25A
|
|
Max Climb Capability
|
25%
|
25%
|
25%
|
|
Maximum allowable working angle
|
1.5° /3°
|
2。/3°
|
1.5° 13°
|
|
yre
|
0381x127mm
|
0381 x 127mm
|
0381 x 127mm
|
|
Weight
|
1845kg
|
2300kg
|
2460kg
|
LTMG always treat after-sale service as important as sale.
Nowadays more than 50 agents and 21 after sales center around the world
can supply LTMG professional after-sale service.All the product of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.Detail clauses and policies please check our website and product certificate.
can supply LTMG professional after-sale service.All the product of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.Detail clauses and policies please check our website and product certificate.
