Quick Details
-
Rated Lifting Moment:
-
1470.4tm
-
Max. Lifting Height:
-
86m
-
Span:
-
16-76m
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
S A N Y
-
Showroom Location:
-
Egypt, Viet Nam,
-
Max. rated lifting capacity:
-
260T
-
Max. load moment:
-
1470.4tm
-
Boom length:
-
16-76m
-
Grade ability:
-
30
-
Emission:
-
CE/ISO9001
-
Overall crane mass:
-
66.7T(main hook)
-
mass of single unit in transport state:
-
38.2T
-
Transport dimension(L*W*H):
-
7160*3360*3260mm
Quick Details
-
Weight (KG):
-
260000
-
Application:
-
port, marine, offshore, construction
-
Rated Loading Capacity:
-
260ton
-
Rated Lifting Moment:
-
1470.4tm
-
Max. Lifting Height:
-
86m
-
Span:
-
16-76m
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
S A N Y
-
Showroom Location:
-
Egypt, Viet Nam,
-
Max. rated lifting capacity:
-
260T
-
Max. load moment:
-
1470.4tm
-
Boom length:
-
16-76m
-
Grade ability:
-
30
-
Emission:
-
CE/ISO9001
-
Overall crane mass:
-
66.7T(main hook)
-
mass of single unit in transport state:
-
38.2T
-
Transport dimension(L*W*H):
-
7160*3360*3260mm
S.an.y SCC2600A crawler crane's maximum lifting capacity is 150ton, with multifunctional boom system, the crane may support a combination of up to 11 types of operating conditions. The 260ton crawler tower suits for various construction requirements.
|
Model |
SCC2600A |
|
|
Boom Operating Condition |
Maximum rated hoisting capacity |
260t |
|
Boom length |
13~52m |
|
|
Boom luffing angle |
30~80° |
|
|
Maximum rated lifting torque |
203t.m |
|
|
Fixed jib Operating Condition |
Longest boom+longest jib |
43+15.25m |
|
Fixed jib offest angle |
10° |
|
|
Working Speed |
Wire speed of main and auxiliary hoist |
0~110m/min |
|
Wire speed of luffing hoist |
0~62m/min |
|
|
Swing speed |
0~3.2rpm |
|
|
Traveling speed |
0~1.39rpm |
|
|
Engine |
Output power/Rated speed |
132/2200 kw/rpm |
|
Transportation Parameters |
Max.transport weight of single piece |
29.5t |
|
Transport dimension(L*W*H) |
7160×3360×3260mm |
|
|
Other Parameters |
Average ground pressure |
0.059MPa |
