for high-rise or heavy-weight work, too. The Crane Trucks differ in lifting capacity and working radius, offering choice for
different job requirements.
- Product Details
- {{item.text}}
Quick Details
-
Application:
-
lifting cargo, construction, transport
-
Rated Lifting Moment:
-
30t.m
-
Span:
-
5M
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
Sinotruk HOWO
-
Machinery Test Report:
-
famous brand
-
Video outgoing-inspection:
-
famous brand
-
Weight (KG):
-
8000 kg
-
Product name:
-
boom truck mounted crane
-
Engine:
-
141hp
-
Certificate:
-
ISO
-
Color:
-
Customer's Requirement
-
Steering:
-
Power Steering
-
Driving type:
-
4x2
-
Chassis brand:
-
Sinotruk HOWO
-
Tire:
-
9.00R20
-
truck crane hydraulic:
-
machine loader truck with crane
Quick Details
-
Rated Loading Capacity:
-
15 TON
-
Max. Lifting Height:
-
20M
-
Engine Brand:
-
famous brand
-
Application:
-
lifting cargo, construction, transport
-
Rated Lifting Moment:
-
30t.m
-
Span:
-
5M
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
Sinotruk HOWO
-
Machinery Test Report:
-
famous brand
-
Video outgoing-inspection:
-
famous brand
-
Weight (KG):
-
8000 kg
-
Product name:
-
boom truck mounted crane
-
Engine:
-
141hp
-
Certificate:
-
ISO
-
Color:
-
Customer's Requirement
-
Steering:
-
Power Steering
-
Driving type:
-
4x2
-
Chassis brand:
-
Sinotruk HOWO
-
Tire:
-
9.00R20
-
truck crane hydraulic:
-
machine loader truck with crane
Product Overview
What is the purpose of crane truck?
Crane trucks are vehicles with a machine designed to help them lift, lower or move heavy objects. They not only transport items
from one place to the next, but also to elevated heights. Without cranes, lifting heavy concrete beams or steel commonly found on
industrial sites is near impossible.
from one place to the next, but also to elevated heights. Without cranes, lifting heavy concrete beams or steel commonly found on
industrial sites is near impossible.
Hot selling Models
4x2 truck mounted crane, loading 10ton, with crane 3ton
6x4 truck mounted crane, loading 25-30ton, with crane 10ton; 12ton; 14ton
8x4 truck mounted crane, loading 40ton, with crane 14ton; 16ton
4x2 truck mounted crane, loading 10ton, with crane 3ton
6x4 truck mounted crane, loading 25-30ton, with crane 10ton; 12ton; 14ton
8x4 truck mounted crane, loading 40ton, with crane 14ton; 16ton
1.
ENGINE
- always giving 100% Standard fitting
WD615 and D12 Engine
The exclusive use of reinforced and wide high-strength and double- wall engine block improves the configuration and quality of key
parts and enhances the reliability and durability of engine greatly.1.High reliability
It keeps a record of continuous running of 40 thousand kilometers for one month. Bench test totaled more than 40000 hours and
vehicle road test accumulated to more than 5 mil- lion kilometers. Its B10 life could reach 1.5 million kilometers.
2. XCMG / HIAB / PALFI NGER brand crane
Crane capacity: 2ton- 16ton
Foldable / Telescopic type.
The exclusive use of reinforced and wide high-strength and double- wall engine block improves the configuration and quality of key
parts and enhances the reliability and durability of engine greatly.1.High reliability
It keeps a record of continuous running of 40 thousand kilometers for one month. Bench test totaled more than 40000 hours and
vehicle road test accumulated to more than 5 mil- lion kilometers. Its B10 life could reach 1.5 million kilometers.
2. XCMG / HIAB / PALFI NGER brand crane
Crane capacity: 2ton- 16ton
Foldable / Telescopic type.
FEATURES AT A GLANCE
Crane Trucks are efficient at moving iron, stone or sand around construction sites. The boom and slewing system make them suitable
for high-rise or heavy-weight work, too. The Crane Trucks differ in lifting capacity and working radius, offering choice for
different job requirements.
for high-rise or heavy-weight work, too. The Crane Trucks differ in lifting capacity and working radius, offering choice for
different job requirements.
Right elevation
Left elevation
Front elevation
PRODUCT SPECIFICATIONS
|
Cabin
|
Driving type 6x4 LHD
|
|
|
|
|||
|
|
HOWO 76 cab, with air condition and one bed, 70°hydraulically tillable to the front as attached photo for ref.
|
|
|
|
|||
|
Vehicle Main Dimensions
|
Overall dimensions (L x W x H) mm
|
11000×2500×3900
|
|
|
|||
|
|
Carriage Size (L x W x H) mm
|
7000×2300×600
|
|
|
|||
|
|
Wheel base (mm)
|
5225+1350
|
|
|
|||
|
|
Wheel track (front/rear) (mm)
|
2022/1830
|
|
|
|||
|
Weight in KGS
|
Tare Weight
|
16100
|
|
|
|||
|
|
payload
|
25000
|
|
|
|||
|
|
Front axles loading capacity
|
1x9000
|
|
|
|||
|
|
Rear axles loading capacity
|
2x16000
|
|
|
|||
|
Max. driving speed(km/h)
|
|
90
|
|
|
|||
|
Engine
|
Brand
|
Sinotruck
|
|
|
|||
|
|
Model
|
WD615.47
|
|
|
|||
|
|
Type
|
4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling
|
|
|
|||
|
|
Horse Power(HP)
|
371
|
|
|
|||
|
|
Emission standard
|
Euro Ⅱ
|
|
|
|||
|
Gearbox
|
HW19710 10 Forwards gear & 2 reverse gear
|
|
|
|
|||
|
Clutch
|
Reinforced diaphragm clutch, diameter 430 mm
|
|
|
|
|||
|
Steering Gear
|
ZF 8118,power steering, hydraulic steering with power assistance
|
|
|
|
|||
|
Tire
|
12R22.5 tubeless tyre 11 pcs including one spare tire |
|
|
|
|||
|
Crane specifications
|
Brand : Chinese brand or Euro brand
|
|
|
|
|||
|
|
Type: Telescopic
|
|
|
|
|||
|
|
Max lift capacity: 10000 kg
|
|
|
|
|||
|
|
Max working radius 15.8 m, Max lifting height : 17.8 m
|
|
|
|
|||
PRODUCT PICTURE
Successful Project
Project in
India
Project in
Thailand
Project in Russia
SIMILAR PRODUCTS
Our Advantages
HOWO 6x4 10 ton Hydraulic Boom Lift Folding Long Boom Arm Crane Mounted Truck
1) Favorable price: Factory price, very competitive in the market. We, SINOTRUK Hubei Huawin is SINOTRUK branch factory.
2) In time Warranty: One year or 100,000km for on road trucks as tractor truck or 6 months or 60,000km for off road trucks as dump truck, which comes to the first for the engine, gear box, and axles. We have offices in Tanzania, Zambia and Philippines to provide warranty service, and we have distributors in different countries all over the world to assist.
3) In time After-sales: We have set up over 240 spare parts centers and service outlets all over 80 countries, professional
after-sales team solve your after sales problem within 3 working days or 5 working days, and all spare parts are available for you.
4) Experienced sales team and logistics team: Experienced sales team are at your service all the time and offer excellent service, professional logistics team work with international shipping company such as MSK&Hyundai to ship your trucks safely and cost-efficiently.
2) In time Warranty: One year or 100,000km for on road trucks as tractor truck or 6 months or 60,000km for off road trucks as dump truck, which comes to the first for the engine, gear box, and axles. We have offices in Tanzania, Zambia and Philippines to provide warranty service, and we have distributors in different countries all over the world to assist.
3) In time After-sales: We have set up over 240 spare parts centers and service outlets all over 80 countries, professional
after-sales team solve your after sales problem within 3 working days or 5 working days, and all spare parts are available for you.
4) Experienced sales team and logistics team: Experienced sales team are at your service all the time and offer excellent service, professional logistics team work with international shipping company such as MSK&Hyundai to ship your trucks safely and cost-efficiently.
