Hydrocyclones petroleum purification desilter Pump Spares Ceramic cyclone

The high efficiency liquid/liquid hydrocyclone provides maximum oil/water separation efficiency, and the solid/liquid hydrocyclone is a cyclone clarifier that offers continuous solids removal from liquid. Both can be used in industrial process water, industrial reuse, oil/water separation, and clarification/separation applications.

The liquid/liquid hydrocyclone is one of the most advanced, yet least complicated oil/water separation devices available. It effectively removes free oil and grease in a compact package, at a cost far less than other types of separators. Liquid/liquid hydrocyclones are ideal for oily process water and oil-field produced water applications.

The solid/liquid hydrocyclone offers effective solids removal in a compact package. It can handle high levels of solids, with removal capabilities down to five micron.Solid/liquid hydrocyclones are ideal for treating oily process water and oil-field produced water, desanding of injection water and for sand jetting systems applications.

Price Check prices for products of interest, you can contact our managers.
Application of Polyurethane hydrocyclones used in the mining industry, which require extreme durability and long service life of products. Under such sufficiently stringent, conditions of application of polyurethane economically advantageous in comparison with conventional tires. After conventional polyurethane wear resistance 3 times higher than that of rubber, and the pressure in compression of polyurethane products may reach 105 MPa. Tensile strength in polyurethane larger than 2.5 times of rubber, and for a temperature range from -50 polyurethane ° C to 80 ° C. We offer manufacturing of polyurethane hydrocyclones for you.

Polyurethane rubber ceramic hydrocyclones is widely used in oil drilling,nonferrous,ferrous and non-metallic concentrator hierarchical classification work in process and many other links,used for deslining,dehydration of slurry materials,oil desanding and desilting device; Mining classification,tailings DAMS;The coal slime water processing and one of the important equipment such as recycling of slime.

Due to the higher recovery rates of the 10, 12, 15 and 20 inch (250, 305, 380 and 500mm) Classifying Cyclones, an optimum amount of fine particles that are washed will be recovered from a dilute stream and transported to downstream dewatering equipment.

Available in 10, 12, 15, and 20-inch (250, 305, 380, 500mm) diameters

Unique lower cone arrangement permits ultra fine separations

Ranging from near 60 to 200 mesh and (0.250 to 0.074mm) D95 separation size

Will increase recovery

Exceptional abrasion resistance

Reaction bonded silicon carbide ceramic in lower cones, nitride bonded silicon, and carbide ceramic in upper sections

Ceramic liners are encased with polyurethane so no steel housings to corrode.

About hydrocyclone package, Normally we pack one roll into the strong woven bag. and then put them into big carton.The complete package is like below image, it is very safe when ship by sea or by air.
