Quick Details
-
Power:
-
110KW
-
Dimension(L*W*H):
-
1.5X2.7X3.8M
-
Weight:
-
45000 kg
-
mixer's power:
-
30x2
-
batcher model0:
-
PLD2400Q-III
-
After Warranty Service:
-
Video technical support
Quick Details
-
Machine Type:
-
Batching machine
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
DKTEC
-
Power:
-
110KW
-
Dimension(L*W*H):
-
1.5X2.7X3.8M
-
Weight:
-
45000 kg
-
mixer's power:
-
30x2
-
batcher model0:
-
PLD2400Q-III
-
After Warranty Service:
-
Video technical support
Performance Characteristics
More economical and fast return on investment, convenient assemble and disassemble,simple operation. can be combined according to users requirements
|
Item
|
|
Unit
|
HZS25
|
HZS35
|
HZS60
|
HZS90
|
|
|
Theory productivity
|
|
m³/h
|
25
|
35
|
60
|
90
|
|
|
Output of mixer
|
|
m³
|
0.5
|
0.75
|
1
|
1.5
|
|
|
Feeding type
|
|
|
Lifting hopper
|
Lifting hopper
|
Belt feeding
|
Belt feeding
|
|
|
Batcher model
|
|
m³
|
PLD800
|
PLD1200-III
|
PLD2400Q-III
|
PLD2400Q-III
|
|
|
Batcher(volume per bin)
|
|
m³
|
3
|
3
|
10
|
10
|
|
|
Batcher(bins amount)
|
|
pc
|
4
|
4
|
4
|
4
|
|
|
Mixer's power
|
|
kw
|
18.5
|
30
|
22x2
|
22x2
|
|
|
Lifting power
|
|
kw
|
5.5
|
7.5
|
15
|
22
|
|
|
Discharge height
|
|
m
|
1.5/2.7/3.8
|
1.5/2.7/3.8
|
3.8
|
3.8
|
|
|
Max weighing
&Accuracy |
Aggregate
|
kg
|
1500±2%
|
2000±2%
|
4000±2%
|
4000±2%
|
|
|
|
Powder material
|
kg
|
300±1%
|
400±1%
|
300±1%
|
300±1%
|
|
Concrete Mixer
*Dry capacity from 750L to 9000L or more.
* Brand available: SICOMA, BHS, WAM, TEKA, or other good quality chinese brand concrete mixer
*All the spare parts for the concrete mixer is also available, such as gearbox, easy wear parts
Concrete Screw Conveyor
*Dry capacity from 750L to 9000L or more.
* Brand available: SICOMA, BHS, WAM, TEKA, or other good quality chinese brand concrete mixer
*All the spare parts for the concrete mixer is also available, such as gearbox, easy wear parts
Aggregate Batcher
*PLD800,PLD1600,PLD2400,PLD3200,PLD4800,PLD6400 is available.
*Accuracy of batching : ±2%
*Belt conveyor speed : 1.25m/s to 2.0m/s
*power : 11 kw to 15 kw
*Accessory : air compressor, vibrator, air cylinder, treatment pad, load cell , air storage tank.
Concrete Silo
*The capacity can be from 50t to 300t, check with us with special model no.
* Bolted type cement silo and welded cement silo is both available.
*All the accessory for the cement silo is available, such as dust collector, butterfly valve, pressure relief valve, level indicator, solenoid valve, swithc , aerator pad.
Control system
*Imported components, reliable performance;
*
Intelligent control, automatic control, manual control in one; with ratio storage, automatic drop compensation, over-scale, under-scale alarm correction;
*
Data cloud storage, printing and other functions;
Successful Project
SIMILAR PRODUCTS
FAQ
1:What kind terms of payment can be accepted?
A:Normally we can work on T/T term or L/C term.
2:Which incoterms 2010 terms can we work?
A:Normally we work on FOB,CFR,CIF.
3:What about the delivery time?
A:7-30 days after receving the deposit.
4:What about the warranty time?
A:12 months after shipment or 2000 working hours.
6.What about the Minimum Order Quantity?
A:The MoQ is 1 pcs.
